IP Bus Clock Header (J11)

J11 selects the speed of the IP bus clock. The IP bus clock speed may be

either 8MHz or the speed of the local bus clock (30MHz for the MC68060,

32MHz for the MC68LC060). The default factory configuration has a

jumper installed on J11 pins 1 and 2, denoting an 8MHz clock.

If the jumper is installed on J11 between pins 2 and 3, the IP bus clock

speed matches that of the MC68060 or MC68LC060 bus clock

(30/32MHz), thus allowing the IP module to run with a 30/32MHz MPU.

Whether the setting is 8MHz or 30/32MHz, all IP ports operate at the sameSRAM Backup Power Source Select Header (J14)

Header J14 determines the source for onboard static RAM backup power

on the MVME172LX.

The following backup power configurations are available for onboard

SRAM through header J14. In the factory configuration, the VMEbus +5V

standby voltage serves as primary and secondary power source (the

onboard battery is disconnected).

speed.IP Bus Strobe Select Header (J18)

Some IP bus implementations make use of the Strobe∗ signal (pin 46) as

an input to the IP modules from the IP2 chip. Other IP interfaces require

that the strobe be disconnected.

With a jumper installed between J18 pins 1 and 2, a programmable

frequency source is connected to the Strobe∗ signal on the IP bus. Refer to

the IP2 chip programming section in the MVME172 Embedded Controller

Programmer’s Reference Guide for additional information.

If the jumper is removed from J18, the strobe line is available for a

sideband type of messaging between IP modules. The Strobe∗ signal is not

connected to any active devices on the board, but it may be connected to a

pull-up resistor.IP DMA Snoop Jumper (J19)

J19 defines the state of the snoop control bus when an IP DMA controller

is local bus master. J19 pins 1 and 2 enable/disable the Snoop Control

signal on the MC68060 processor (pins 3-4 have no function on

MVME172LX boards)For the MVME172LX, shorting pins 1-2 enables snooping. Leaving pins

1-2 disconnected (the factory configuration) inhibits snooping. With

snooping enabled, the snoop signal to the MC68060 processor is driven

low during IP DMA operations.
