系统控制器选择标题（J3）标题J3允许您选择MVME147作为系统控制器。拆下跨接导线后，该模块不用作系统控制器。模块出厂时已安装跳线（系统控制器）。串行端口4时钟配置选择标头（J8、J9）串行端口4可以配置为使用TRXC4和RTXC4信号线。

DS200ADGIH1AAA燃机模块MVME147上的标题J8和J9模块配置部分时钟信号。剩下的时钟线的配置是使用上的报头J15完成的MVME712M模块。参考MVME712M过渡收割台J15的模块和P2适配器板用户手册配置模块在出厂时带有插脚2上的跳线J8的3（接收RTXC4）和J9的引脚1和2（驱动TRXC4）。安装说明配置MVME147的标头并安装如前所述，将选定的ROM安装在插槽中系统中的MVME147模块如下：1、关闭所有设备电源并断开电源来自交流电源的电缆。在通电时连接模块可能会导致损坏模块上的部件。可能导致死亡的危险电压包括：存在于该设备中。在以下情况下，请格外小心：处理、测试和调整。2、按照设备说明卸下机箱盖用户手册。3.从以下位置的相应卡槽中卸下填充板：机箱的前部和后部（如果机箱有后部卡保持架）。如果MVME147配置为系统控制器，将其安装在最左侧的卡插槽（插槽1）中，以启动总线正确授予菊花链。将安装MVME147在底盘前部；MVME712过渡模块可以安装在机箱的前部或后部。注：每个MVME147都分配了一个以太网站住址地址是08003E2xxxxx，其中xxxxx是分配给模块的唯一编号；i、 e.每MVME147对于xxxxx具有不同的值。每个以太网站地址都显示在标签上至MVME147的背板连接器P2。在里面附加

System Controller Select Header (J3)

Header J3 allows you to select the MVME147 as system controller.

With the jumper removed, the module is not used as system

controller. The module is shipped with the jumper installed

(system controller). Serial Port 4 Clock Configuration Select Headers (J8, J9)

Serial port 4 can be configured to use clock signals provided by the

TRXC4 and RTXC4 signal lines. Headers J8 and J9 on the MVME147

module configure part of the clock signals. The remaining

configuration of the clock lines is accomplished using header J15 on

the MVME712M module. Refer to the MVME712M Transition

Module and P2 Adapter Board User's Manual for header J15

configuration. The module is shipped with the jumper on pins 2

and 3 of J8 (receiving RTXC4), and on pins 1 and 2 of J9 (driving

TRXC4).Installation Instructions

When you have configured the MVME147’s headers and installed

the selected ROMs in the sockets as described previously, install the

MVME147 module in the system as follows:

1. Turn all equipment power OFF and disconnect the power

cable from the AC power source. Connecting modules while power is applied may result

in damage to components on the module.Dangerous voltages, capable of causing death, are

present in this equipment. Use extreme caution when

handling, testing, and adjusting.

2. Remove the chassis cover as instructed in the equipment

user's manual.

3. Remove the filler panel(s) from the appropriate card slot(s) at

the front and rear of the chassis (if the chassis has a rear card

cage). If the MVME147 is configured as the system controller,

install it in the left-most card slot (slot 1) to initiate the bus

grant daisy-chain correctly. The MVME147 is to be installed

in the front of the chassis; the MVME712 transition module

may be installed in the front or rear of the chassis.

Note Every MVME147 is assigned an Ethernet station

address. The address is $08003E2xxxxx where xxxxx is

the unique number assigned to the module; i.e., every

MVME147 has a different value for xxxxx.

Each Ethernet station address is displayed on a label

attached to the MVME147’s backplane connector, P2. In

addition
