MVME6100自动化卡件,MOTOROLA培训教程
如果摩托罗拉网络软件运行在MVME147，它使用BBRAM中的2xxxxx值来填写以太网站地址（$08003E2xxxxx）。您必须确保保持2xxxxx的值在BBRAM中。如果在BBRAM中丢失2xxxxx的值，则使用背板连接器P2标签上的编号为恢复它。注意，MVME147Bug包括LSAD”命令，用于检查和更新BBRAM xxxxx值。
MVME6100自动化卡件如果非摩托罗拉网络软件运行在MVME147，它必须设置79C90，以便以太网车站地址显示在前面板标签上，用于确保模块具有全球唯一的以太网车站地址。将MVME147插入所选卡槽。确保模块正确安装在背板。用螺钉将模块固定在机箱中假如为了正确操作，需要一个32位VMEbus背板应使用。这确保了电力充足分布在连接器P1和P2上足够的电源引脚上。5.从机箱上的收割台上拆下IACK和BG跳线安装MVME147的卡槽的背板（如适用）。.请参阅随附的MVME712用户手册MVME712转换模块，并安装转换板、P2适配器板和所需的任何外围电缆，根据此处给出的安装说明。7、连接用作系统的终端控制台至标有串行端口1的串行输入/输出端口/控制台在MVME712模块上。要使用147Bug，请设置终端
具体如下：–每个字符8位–每个字符一个停止位–奇偶校验禁用（无奇偶校验）–9600波特，符合MVME147端口的默认波特率通电时。
If Motorola networking software is running on an MVME147, it uses the 2xxxxx value from BBRAM to complete the Ethernet station address ($08003E2xxxxx). You must ensure that the value of 2xxxxx is maintained in BBRAM. If the value of 2xxxxx is lost in BBRAM, use the number on the backplane connector P2 label to restore it. Note that MVME147Bug includes the “LSAD” command for examining and updating the BBRAM xxxxx value. If non-Motorola networking software is running on an MVME147, it must set up the 79C90 so that the Ethernet station address is that shown on the front panel label to ensure that the module has a globally unique Ethernet station address. 4. Insert the MVME147 into the selected card slot. Be sure the module is seated properly into the connectors on the backplane. Fasten the module in the chassis with the screws provided. For proper operation, a 32-bit VMEbus backplane should be used. This ensures that power is sufficiently distributed over enough power pins on connectors P1 and P2. 5. Remove IACK and BG jumpers from the header on chassis backplane for the card slot in which the MVME147 is installed (if applicable). 6. Refer to the MVME712 user’s manual provided with your MVME712 transition module, and install the transition board, P2 adapter board, and any peripheral cables needed, according to the installation instructions given there. 7. Connect the terminal which is to be used as the system console to the serial I/O port marked SERIAL PORT 1/CONSOLE on the MVME712 module. To use 147Bug, set up the terminal as follows: – Eight bits per character – One stop bit per character – Parity disabled (no parity) – 9600 baud to agree with the MVME147 ports’ default baud rate at power-up.
