以太网TCP/IP网络的编程器和PLC您必须在以太网接口中设置IP地址。设置IP地址后，连接PLC和运行Windows软件的程序员以太网接口。有关以太网TCP/IP的更多详细信息，请参阅TCP/IP以太网通信（类型2）用户手册和Windows编程手册，GFK-1295。配置IC697 CPU和输入/输出系统配置为基于MS-DOS或Windows的编程软件。

BASLER A404k工业相机没有DIP开关或跳线用于配置系统。CPU验证实际通电时的模块和机架配置，以及在运行期间定期。实际配置必须与编程的相同配置偏差报告给CPU配置故障的报警处理器功能回答参考参考文献1了解配置功能。电池安装锂电池（IC697ACC701），如图所示如图2所示。该电池维护程序和数据当电源断开并操作日历时钟。确保安装新电拆卸旧电池之前。如果在通电期间诊断检测到电池电量低，模块OK LED（顶部LED）将不亮起。具体的电池电量低状态的指示详见参考2。卸下模块当发生以下情况时，应遵循以下说明从机架中的插槽中卸下模块。
牢牢抓住电路板的顶部和底部将拇指放在面板正面的板盖上将盖子和手指放在塑料夹子上封面的背面。
挤压盖背面的机架夹用手指将夹子从机架导轨并用力拉动板将其卸下从背板连接器。
沿卡导轨滑动板并卸下它来自机架。

programmer and PLC to the Ethernet TCP/IP network

you must set the IP address in the Ethernet Interface.

After setting the IP address, connect the PLC and the

programmer running Windows software to the

Ethernet Interface.

For more detailed information on Ethernet TCP/IP,

refer to the TCP/IP Ethernet Communications (Type 2)

User’s Manual, and the Windows programming

manual, GFK-1295.Configuration

The IC697 CPU and I/O system is configured with

MS-DOS or Windows based programming software.

There are no DIP switches or jumpers used to

configure the system. The CPU verifies the actual

module and rack configuration at power-up and

periodically during operation. The actual

configuration must be the same as the programmed

configuration. Deviations are reported to the CPU

alarm processor function for configured fault

response. Consult Reference 1 for a description of

configuration functions.Battery

A lithium battery (IC697ACC701) is installed as shown

in Figure 2. This battery maintains program and data

memory when power is removed and operates the

calendar clock. Be sure to install the new battery

before removing the old battery. If during power-up

diagnostics a low battery is detected, the MODULE

OK LED (top LED) will not stay on. Specific

indication of a low battery state is detailed in

Reference 2.Removing a Module

The instructions below should be followed when

removing a module from its slot in a rack.

Grasp the board firmly at the top and bottom of

the board cover with your thumbs on the front of

the cover and your fingers on the plastic clips on

the back of the cover.

Squeeze the rack clips on the back of the cover

with your fingers to disengage the clip from the

rack rail and pull the board firmly to remove it

from the backplane connector.

Slide the board along the card guide and remove

it from the rack.
