3BHE014105R0001 5SXE08-0166变频器可控硅模块,ABB使用区域

模块应通电，顶部LED应眨眼诊断完成时成功地，顶部LED保持亮起，第二个和第三个LED熄灭。如果钥匙开关处于断开位置。CPU现在准备编程（如果并联，则CPU无论钥匙位置如何，都可以编程）。之后该程序已经过验证，切换开关可以移动到适当的操作模式位置。LED指示切换开关的位置，内存保护状态和程序状态。

3BHE014105R0001 5SXE08-0166变频器可控硅模块编程器连接，并行对于并行接口（仅限MS-DOS编程器）编程器连接到总线上的顶部端口发射器模块（IC697BEM713）。参考参考文献1有关编程功能的描述，请参阅串行端口15针D接头提供与CPU上的RS-485兼容串行端口（见图3）。此端口提供到工作站的串行连接安装在编程计算机中的接口板。串行连接也可以通过串行CPU上的端口到编程上的串行端口计算机或其他串行设备RS-422/RS-485至RS-232转换器（IC690ACC900）或RS-232至RS-422微型转换器（IC690ACC901）。这可以使用可用的电缆进行连接，也可以使用可能会建造电缆以满足您的特定需求应用有关更多信息，请参阅参考3串行通信。有关TMR配置的更多详细信息系统和PLC之间的通信在系统中，指模块化冗余灵活三重模块冗余（TMR）系统用户手册。程序员连接，以太网TCP/IP通过以太网TCP/IP连接程序员网络需要安装以太网接口PLC中的模块。这可以是以太网控制器、IC697CMM741或以太网接口（类型2） ，IC697CMM742。在连接之前

The module should power up and the top LED should

blink. When the diagnostics have completed

successfully, the top LED stays on and the second and

third LEDs are off. The fourth LED is off if the

keyswitch is in the OFF position. The CPU is now

ready to be programmed (if connected parallel, the CPU

can be programmed regardless of key position). After

the program has been verified the toggle switch can be

moved to the appropriate operation mode position.

The LEDs indicate the position of the toggle switch,

memory protection status, and the state of the program.

Programmer Connection, Parallel

For a parallel interface (MS-DOS programmer only) the

programmer is connected to the top port on the Bus

Transmitter Module (IC697BEM713). Consult Reference

1 for a description of programming functionsSerial Port

The 15-pin D-connector provides the connection to an

RS-485 compatible serial port on the CPU (see Figure 3).

This port provides a serial connection to a Work Station

Interface board installed in the programming computer.

The serial connection can also be made from the serial

port on the CPU to the serial port on the programming

computer, or other serial device, through the

RS-422/RS-485 to RS-232 Converter (IC690ACC900) or

RS-232 to RS-422 Miniconverter (IC690ACC901). This

connection can be made with available cables or you

may build cables to fit the needs of your particular

application. See reference 3 for more information on

serial communications.For more detailed information on configuration of TMR

systems and communications between PLCs in thesystem, refer to the Modular Redundancy Flexible Triple

Modular Redundant (TMR) System User’s Manual.

Programmer Connection, Ethernet TCP/IP

Connecting your programmer via an Ethernet TCP/IP

network requires installation of an Ethernet Interface

module in the PLC. This can be either the Ethernet

Controller, IC697CMM741, or Ethernet Interface (Type

2), IC697CMM742. Before connecting your
