NI PXIe-6361高性能数据采集卡产品特点

作者:ysh 发布时间:2023-05-06 10:21:52 1158次浏览

NI PXIe-6361高性能数据采集卡产品特点1.产 品 资 料 介 绍:中文资料:NI PXIe-6361是一款高性能数据采集卡,具有广泛的应用范围。下面是对该产品的特点、使用方法以及参数的详细介绍:产品特点:高性能数据采集:NI PXIe-6361采用了高速模数转换器(ADC),可实现高精度、高速率的模拟信号采集。多通道采集:该采集卡具有16个模拟输入通道,可以同时采集多个信号通道的数据。高

NI PXIe-6361高性能数据采集卡产品特点

1.产 品 资 料 介 绍:

中文资料:

NI PXIe-6361是一款高性能数据采集卡,具有广泛的应用范围。下面是对该产品的特点、使用方法以及参数的详细介绍:

产品特点:

  1. 高性能数据采集:NI PXIe-6361采用了高速模数转换器(ADC),可实现高精度、高速率的模拟信号采集。
  2. 多通道采集:该采集卡具有16个模拟输入通道,可以同时采集多个信号通道的数据。
  3. 高采样率:支持高达2 MS/s的采样率,可满足对高速动态信号的采集需求。
  4. 低噪声和高分辨率:具备优秀的信噪比和分辨率,可实现对微弱信号的准确采集和测量。
  5. 多种测量功能:支持模拟输入、数字输入/输出、计时器/计数器和触发等功能,满足各种测试和测量应用的需求。

使用方法:

  1. 硬件连接:将NI PXIe-6361插入PXI Express插槽,并连接相应的信号源或传感器到模拟输入端口。
  2. 驱动程序安装:安装NI-DAQmx驱动程序,该驱动程序提供了使用和配置采集卡的接口。
  3. 软件编程:使用支持NI-DAQmx的编程环境(如LabVIEW、C/C++、Python等),编写程序以配置和控制采集卡,以及进行数据采集和分析。

参数详情:

  • 模拟输入通道数:16
  • 模拟输入分辨率:16位
  • 采样率范围:100 kS/s - 2 MS/s
  • 输入电压范围:±10 V
  • 数字输入/输出通道数:8
  • 计时器/计数器通道数:2
  • 供电方式:PXI Express总线供电或外部电源供电
  • 接口类型:PCI Express x1或更高版本
  • 支持的操作系统:Windows、Linux

英文资料:

NI PXIe-6361 is a high-performance data acquisition card with a wide range of applications. The following is a detailed introduction to the characteristics, usage methods, and parameters of the product:

Product features:

High performance data acquisition: NI PXIE-6361 adopts a high-speed analog-to-digital converter (ADC), which can achieve high-precision and high-speed analog signal acquisition.

Multi channel acquisition: This acquisition card has 16 analog input channels and can simultaneously collect data from multiple signal channels.

High sampling rate: Supports a sampling rate of up to 2 MS/s, which can meet the collection needs of high-speed dynamic signals.

Low noise and high resolution: With excellent signal-to-noise ratio and resolution, it can achieve accurate collection and measurement of weak signals.

Multiple measurement functions: support analog input, digital input/output, timer/counter, and trigger functions to meet the needs of various testing and measurement applications.

usage method:

Hardware connection: Insert NI PXIe-6361 into the PXI Express slot and connect the corresponding signal source or sensor to the analog input port.

Driver installation: Install the NI-DAQmx driver, which provides an interface for using and configuring the acquisition card.

Software programming: Using a programming environment that supports NI-DAQmx (such as LabVIEW, C/C++, Python, etc.), write programs to configure and control the acquisition card, as well as perform data collection and analysis.

Parameter details:

Number of analog input channels: 16

Analog input resolution: 16 bits

Sampling rate range: 100 kS/s -2 MS/s

Input voltage range: ± 10 V

Number of digital input/output channels: 8

Timer/Counter Channel Count: 2

Power supply method: PXI Express bus power supply or external power supply

Interface type: PCI Express x1 or higher

Supported operating systems: Windows, Linux


2.产      品      展      示


NI PXIe-6361.png
