安装说明本节包括：❏ 在04220FL11232A上安装IndustryPack（IPs）❏ 在VME机箱中安装MVME172LX❏ 与安装相关的系统注意事项。确保根据需要安装EPROM设备。确保所有收割台跳线根据需要进行配置。04220FL11232A的IP安装04220FL11232A上最多可安装两个IP模块。安装04220FL11232A上的IP如下：1.每个IP模块有两个50针连接器，插入两个MVME172LX上对应的50针连接器：J5/J6，J7/J8。MVME172LX连接器位置见图2-1。

GE 04220FL11232A控制器–调整仪表板模块的方向，使锥形连接器外壳匹配正确地将IP_a插入连接器J5和J6；将IP_b插入J7和J8。如果使用双倍大小的IP，请将IP_ab插入J5、J6、J7、，和J8。2.后面提供两个额外的50针连接器（J3和J4）用于外部电缆连接的MVME172LX前面板IP模块。之间存在一对一的对应关系电缆连接器上的信号和相关IP连接器（即J4具有与J5相同的IP_a信号；J3具有与J7相同的IP_b信号）。–根据需要将用户提供的50针电缆连接到J3和J4。因为对每种不同类型的摩托罗拉不提供这些电缆。–将IP电缆从MVME172LX的窄槽中取出前面板并将其连接到相应的外部设备，取决于特定IP MVME172LX安装的性质安装了EPROM和IP模块并正确配置了标头，按照以下步骤在VME机箱中安装MVME172LX：1、关闭所有设备电源，断开电源线来自交流电源。

通电时插入或卸下模块可能会导致模块组件损坏。这台设备。在搬运、测试、，和调整。2.按照用户手册中的说明卸下机箱盖设备3.将填充板从要插入的卡槽中卸下安装MVME172LX。

Installation Instructions

This section covers:

❏ Installation of IndustryPacks (IPs) on the MVME172LX

❏ Installation of the MVME172LX in a VME chassis

❏ System considerations relevant to the installation. Ensure that

EPROM devices are installed as needed. Ensure that all header

jumpers are configured as desired.

IP Installation on the MVME172LX

Up to two IP modules may be installed on the MVME172LX. Install the

IPs on the MVME172LX as follows:

1. Each IP module has two 50-pin connectors that plug into two

corresponding 50-pin connectors on the MVME172LX: J5/J6,

J7/J8. See Figure 2-1 for the MVME172LX connector locations.

– Orient the IP module(s) so that the tapered connector shells mate

properly. Plug IP_a into connectors J5 and J6; plug IP_b into J7

and J8. If a double-sized IP is used, plug IP_ab into J5, J6, J7,

and J8.

2. Two additional 50-pin connectors (J3 and J4) are provided behind

the MVME172LX front panel for external cabling connections to

the IP modules. There is a one-to-one correspondence between the

signals on the cabling connectors and the signals on the associated

IP connectors (i.e., J4 has the same IP_a signals as J5; J3 has the

same IP_b signals as J7).

– Connect user-supplied 50-pin cables to J3 and J4 as needed.

Because of the varying requirements for each different kind of

IP, Motorola does not supply these cables.

– Bring the IP cables out the narrow slot in the MVME172LX

front panel and attach them to the appropriate external

equipment, depending on the nature of the particular IP(s)MVME172LX Installation

With EPROMs and IP modules installed and headers properly configured,

proceed as follows to install the MVME172LX in the VME chassis:

1. Turn all equipment power OFF and disconnect the power cable

from the AC power source.
