SCSI Interface

The MVME162 supports mass storage subsystems through the industrystandard SCSI bus. These subsystems may include hard and floppy disk

drives, streaming tape drives, and other mass storage devices. The SCSI

interface is implemented using the NCR 53C710 SCSI I/O controller.

Support functions for the NCR 53C710 are provided by the MCchip. Refer to

the NCR 53C710 user’s guide and to the MVME162 Embedded Controller

Programmer’s Reference Guide for detailed programming information. Refer to

the MVME712-12, MVME712-13, MVME712A, MVME712AM, and

MVME712B Transition Modules and LCP2 Adapter Board User’s Manual or to the

MVME712M Transition Module and P2 Adapter Board User’s Manual for the pin

assignments of the transition module SCSI connectors.

SCSI Termination

The individual configuring the system must ensure that the SCSI bus is

properly terminated at both ends.

The MVME162 provides sockets for SCSI bus terminators on the P2 adapter

board or the LCP2 adapter board. If the SCSI bus ends at the adapter board,

then termination resistors must be installed on the adapter board. +5V power

to the SCSI bus TERMPWR signal and termination resistors is provided

through a fuse located on the adapter board.

Local Resources

The MVME162 includes many resources for the local processor. These include

tick timers, software programmable hardware interrupts, watchdog timer,

and local bus timeout.Programmable Tick Timers

Four 32-bit programmable tick timers with 1 µs resolution are provided in the

MCchip and two 32-bit programmable tick timers are provided in the optional

VMEchip2. The tick timers can be programmed to generate periodic

interrupts to the processor. Refer to the MCchip and VMEchip2 descriptions

in the MVME162 Embedded Controller Programmer’s Reference Guide for detailed

programming information.

Watchdog Timer

A watchdog timer is provided in both the MCchip and the optional VMEchip2.

The timers operate independently but in parallel. When the watchdog timers

are enabled, they must be reset by software within the programmed time or

they will time out. The watchdog timers can be programmed to generate a

SYSRESET signal, local reset signal, or board fail signal if they time out. Refer

to the VMEchip2 and MCchip descriptions in the MVME162 Embedded

Controller Programmer’s Reference Guide for detailed programming information.
