416NHM30030可编程模块，SCHNEIDER产品重量

安装安装底座要将安装基座安装在DIN导轨上，请按以下步骤进行。1.将安装底座垂直放置在已安装装置上方（适配器、电源或现有模块）。2、向下滑动安装底座，允许联锁侧与相邻模块或适配器接合的零件。3、用力按压，将安装座固定在DIN导轨上。这个安装底座将卡入到位。

416NHM30030可编程模块要从DIN导轨上拆下安装底座，请拆下并使用小刃螺丝刀旋转底座将螺钉锁定到垂直位置。这将解除锁定机械装置然后笔直向上提起以将其拆下。安装输入/输出模块模块可以在基座安装之前或之后安装。制作在安装前，确保安装底座正确锁定将模块插入安装基座。此外，确保安装底座锁紧螺钉相对于底座水平放置。顺时针方向安装底座，直到达到安装的模块类型与基础有关钥匙开关位置，请参阅第1-17页。确保DIN导轨锁紧螺钉处于水平位置位置（如果锁定机构已解锁。）3.将模块直接向下插入安装底座，然后按下以固定。模块将锁定到位。安装可拆卸接线板（RTB）可拆卸接线板随接线座一起提供装配要拆卸，拉起RTB手柄。这允许必要时拆卸和更换安装底座，无需拆卸任何导线。要重新插入可拆卸接线板，按以下步骤进行。

Installing the Mounting Base

To install the mounting base on the DIN rail, proceed as follows.

1. Position the mounting base vertically above the installed units

(adapter, power supply or existing module).

2. Slide the mounting base down allowing the interlocking side

pieces to engage the adjacent module or adapter.

3. Press firmly to seat the mounting base on the DIN rail. The

mounting base will snap into place.

4. To remove the mounting base from the DIN rail, remove the

module, and use a small bladed screwdriver to rotate the base

locking screw to a vertical position. This releases the locking

mechanism. Then lift straight up to remove.Installing the I/O Module

The module can be installed before or after base installation. Make

sure that the mounting base is correctly keyed before installing the

module into the mounting base. In addition, make sure the mounting

base locking screw is positioned horizontal referenced to the base.

1. Using a bladed screwdriver, rotate the keyswitch (2) on the

mounting base clockwise until the number required for the

type of module being installed aligns with the notch in the

base. Refer to page 1-17 for the keyswitch position.Make certain the DIN rail locking screw is in the horizontal

position. (You cannot insert the module if the locking

mechanism is unlocked.)

3. Insert the module straight down into the mounting base and

press to secure. The module will lock into place.Installing the Removable Terminal Block (RTB)

A removable terminal block is supplied with your wiring base

assembly. To remove, pull up on the RTB handle. This allows the

mounting base to be removed and replaced as necessary without

removing any of the wiring. To reinsert the removable terminal block,

proceed as follows.
