369-HI-R-M-F-E-H-E继电器模块,GE通用电气以太网接口可以配置为使用SNTP来同步制作EGD交换。以太网接口实现了1类和2类设备的功能。应用程序中可以使用COMMREQ驱动的EGD命令进行读写数据输入CPU或其他EGD 2类设备。Ethernet OK LED指示模块是否能够执行正常操作。正常操作时，该LED亮起所有其他操作都会闪烁。如果是硬件或运行时出现故障时，EOK LED闪烁两位数错误。
369-HI-R-M-F-E-H-E继电器模块▪ LAN OK LED指示进入以太网。这个当通过网络发送或接收数据时，LAN LED闪烁指向或来自以太网接口的网络。它保持打开状态当以太网接口未主动访问网络时但以太网物理接口可用，并且其中一个或两个都可用以太网端口可运行。除非另有说明，否则它将关闭软件加载正在发生。▪ 正常操作期间，Log Empty LED亮起。如果一个事件已被记录。▪ 两个以太网网络活动指示灯（链路）指示网络链接状态和活动。▪ 两个以太网网络速度指示灯（100Mbps）指示网络数据速度（10（关）或100 Mb/s（开））。以太网重启按钮此按钮用于手动重新启动以太网固件无需对整个系统进行电源循环。它是凹进去的，以防止意外操作。连接器该模块有两个10BaseT/100BaseTX以太网端口连接器。网络只有一个接口（只有一个以太网MAC地址，只有一个IP地址）。它还有一个Station Manager（RS-232）串行端口。特征单插槽CPU在内存中提供1 MB电池支持的内存相同的插槽（最多512 KB可供梯形图应用程序）支持浮点计算高达12K的离散输入和输出（任何混合-仅单工模式）；2048表决离散输入，2048表决离散输出高达8K模拟输入（仅限单工模式）和8K模拟输出（仅限于单工模式）；1024票模拟输入
The Ethernet Interface can be configured to use SNTP to synchronize the timestamps of
produced EGD exchanges.
The Ethernet Interface implements the capabilities of a Class 1 and Class 2 device.
COMMREQ-driven EGD Commands can be used in the application program to read and write
data into the CPU or other EGD Class 2 devices.The Ethernet OK LED indicates whether the module is able to
perform normal operation. This LED is On for normal operation
and flashing for all other operations. If a hardware or runtime
failure occurs, the EOK LED blinks a two-digit error.
▪ The LAN OK LED indicates access to the Ethernet network. The
LAN LED blinks when data is being sent or received over the
network directed to or from the Ethernet interface. It remains On
when the Ethernet interface is not actively accessing the network
but the Ethernet physical interface is available and one or both of
the Ethernet ports is operational. It is Off otherwise unless
software load is occurring.
▪ The Log Empty LED is On during normal operation. It is Off if an
event has been logged.
▪ Two Ethernet network activity LEDS (LINK) indicate the network
link status and activity.
▪ Two Ethernet network speed LEDS (100Mbps) indicates the
network data speed (10 (off) or 100 Mb/sec (on)).
Ethernet Restart Pushbutton
This pushbutton is used to manually restart the Ethernet firmware
without power cycling the entire system. It is recessed to prevent
accidental operation.
Connectors
The module has two 10BaseT/100BaseTX Ethernet Network Port
Connectors. There is only one interface to the network (only one
Ethernet MAC address and only one IP address).
It also has a Station Manager (RS-232) Serial Port.Features
Single slot CPU
Provides 1 Mbyte of battery-backed memory in the
same slot (up to 512 Kbytes available for use by
ladder diagram application program)
Supports floating point calculations
Up to 12K discrete inputs and outputs (any mix -
simplex mode only); 2048 voted discrete inputs, 2048
voted discrete outputs
