If the data in the BBRAM is lost, use the number on the label on backplane

connector P2 to restore it.

The Ethernet transceiver interface is located on the MVME172LX main

board, and the industry standard connector is located on its front panel

Support functions for the 82596CA are provided by the MC2chip. Refer to

the 82596CA user’s guide and to the MC2chip description in the

MVME172 VME Embedded Controller Programmer’s Reference Guide

for detailed programming information.

SCSI Interface

The MVME172LX supports mass storage subsystems through the

industry-standard SCSI bus. These subsystems may include hard and

floppy disk drives, streaming tape drives, and other mass storage devices.

The SCSI interface is implemented using the NCR 53C710 SCSI I/O

controller. Support functions for the 53C710 are provided by the MC2chip. Refer to

the NCR 53C710 user’s guide and to the MC2chip in the MVME172 VME

Embedded Controller Programmer’s Reference Guide for detailed

programming information.

SCSI Termination

It is important that the SCSI bus be properly terminated at both ends.

The MVME172LX main board provides terminators for the SCSI bus. The

SCSI terminators are enabled/disabled by a jumper on header J12. If the

SCSI bus ends at the MVME172LX, a jumper must be installed between

J12 pins 1 and 2.

The FUSES LED (part of DS2) on the MVME172LX front panel monitors

the SCSI bus TERMPWR signal in addition to LAN power and

IndustryPack power; the FUSES LED illuminates when all fuses are

operational. The fuses are solid-state devices that reset when the short is

removed.

Because any device on the SCSI bus can provide TERMPWR, the FUSES

LED does not directly indicate the condition of the fuse.

Local Resources

The MVME172LX includes many resources for the local processor. These

include tick timers, software-programmable hardware interrupts, a

watchdog timer, and a local bus timeout.

Programmable Tick Timers

Four 32-bit programmable tick timers with 1µs resolution are provided in

the MC2chip and two 32-bit programmable tick timers are provided in the

optional VMEchip2. The tick timers may be programmed to generate

periodic interrupts to the processor. Refer to the VMEchip2 and MC2chip

in the MVME172 VME Embedded Controller Programmer’s Reference

Guide for detailed programming information
