NI PXI-2797模拟信号路由器功能
1.产 品 资 料 介 绍：
中文资料：
NI PXI-2797是一款高性能的模拟信号路由器，它是国家仪器（National Instruments）的一部分，属于NI的PXI系列产品。以下是关于NI PXI-2797的配置说明、功能和应用领域的介绍：
配置说明：
- PXI-2797是一款2x2模拟信号路由器，具有两个输入通道和两个输出通道。每个通道都支持高达16个不同的模拟信号源或目的地。
- 它采用了PXI（PCI eXtensions for Instrumentation）总线接口，可以与其他PXI设备和模块一起使用，实现灵活的系统集成。
功能和作用：
- NI PXI-2797的主要功能是实现模拟信号的路由和切换。它可以将特定输入通道的信号路由到目标输出通道，或者将多个输入通道的信号合并到一个输出通道上。
- 该路由器支持高速切换和低延迟传输，可以在短时间内完成信号的切换，同时保持信号的高质量和准确性。
- PXI-2797还提供了灵活的软件编程接口，可以通过编程方式控制信号路由和切换，从而实现自动化测试和测量应用。
应用领域：
- 测试和测量系统：PXI-2797可以与其他仪器和设备一起使用，构建出高性能的测试和测量系统。它可以用于模拟信号的切换、多路复用、分发等任务，广泛应用于自动测试设备（ATE）、数据采集系统等领域。
- 通信系统：在通信系统中，PXI-2797可以用于信号的切换、路由和连接管理。它可以用于实现多通道的信号监测、模拟前端处理、通道切换等功能。
- 研发实验室：研发实验室通常需要进行各种信号路由和切换实验，PXI-2797提供了灵活的配置和编程接口，方便研究人员进行实验和验证。
总结： NI PXI-2797是一款高性能的模拟信号路由器，可用于信号的切换、路由和连接管理。它在测试和测量系统、通信系统以及研发实验室等领域都有广泛的应用。
英文资料：
NI PXI-2797 is a high-performance analog signal router that is part of the National Instruments and belongs to NI's PXI series of products. The following is an introduction to the configuration, functions, and application areas of NI PXI-2797:
Configuration instructions:
PXI-2797 is a 2x2 analog signal router with two input channels and two output channels. Each channel supports up to 16 different analog signal sources or destinations.
It adopts a PXI (PCI eXtensions for Instrumentation) bus interface and can be used with other PXI devices and modules to achieve flexible system integration.
Function and function:
The main function of NI PXI-2797 is to achieve routing and switching of analog signals. It can route signals from specific input channels to the target output channel, or merge signals from multiple input channels onto one output channel.
This router supports high-speed switching and low latency transmission, which can complete signal switching in a short time while maintaining high quality and accuracy of the signal.
PXI-2797 also provides a flexible software programming interface that can control signal routing and switching through programming, thus achieving automated testing and measurement applications.
Application field:
Testing and Measurement System: PXI-2797 can be used together with other instruments and equipment to build high-performance testing and measurement systems. It can be used for tasks such as switching, multiplexing, and distribution of analog signals, and is widely used in fields such as automatic test equipment (ATE) and data acquisition systems.
Communication system: In communication systems, PXI-2797 can be used for signal switching, routing, and connection management. It can be used to achieve multi-channel signal monitoring, analog front-end processing, channel switching, and other functions.
R&D laboratory: R&D laboratories usually need to conduct various signal routing and switching experiments. PXI-2797 provides flexible configuration and programming interfaces, making it convenient for researchers to conduct experiments and verifications.
Summary:
NI PXI-2797 is a high-performance analog signal router that can be used for signal switching, routing, and connection management. It has extensive applications in testing and measurement systems, communication systems, and research and development laboratories.
2.产 品 展 示
