NI PXI-2530B多路继电器模块
1.产 品 资 料 介 绍：
中文资料：
NI PXI-2530B是一种多路继电器模块，用于在PXI平台上进行高速切换和路由任务。下面是该模块的配置说明、功能作用以及应用领域的一些信息：
配置说明：
- NI PXI-2530B采用了PXI总线架构，适用于与其他PXI模块一起使用。
- 它提供了16个单刀双掷（SPDT）继电器通道。
- 模块配置尺寸为3U，并与PXI机箱兼容。
功能作用：
- PXI-2530B的主要功能是实现高速和精确的信号切换。它可以通过电子控制在不同的继电器通道之间进行切换，从而实现信号的路由。
- 这个模块具有较快的切换速度和低延迟，适用于需要高速切换的测试和测量应用。
应用领域：
- 自动测试设备（ATE）：PXI-2530B可用于ATE系统中的信号切换和路由任务，如电路板测试、电子元器件测试等。
- 自动化控制系统：在自动化环境中，该模块可以用于控制和切换不同的信号源、传感器或执行器，以实现系统的监控和控制。
- 通信和无线电测试：PXI-2530B可用于测试和验证通信设备、射频设备以及其他无线电设备的信号切换需求。
- 实验室测量和研究：该模块适用于需要在实验室环境中进行快速切换和路由的测量和研究任务。
总之，NI PXI-2530B是一个高速、精确的继电器模块，可用于PXI平台上的信号切换和路由任务。它在自动测试设备、自动化控制系统、通信和无线电测试以及实验室测量和研究等领域都有广泛的应用。
英文资料：
NI PXI-2530B is a multi-channel relay module used for high-speed switching and routing tasks on the PXI platform. The following are the configuration instructions, functional functions, and some information about the application field of this module:
Configuration instructions:
The NI PXI-2530B adopts a PXI bus architecture and is suitable for use with other PXI modules.
It provides 16 single pole double throw (SPDT) relay channels.
The module configuration size is 3U and compatible with PXI chassis.
Function:
The main function of PXI-2530B is to achieve high-speed and precise signal switching. It can switch between different relay channels through electronic control to achieve signal routing.
This module has fast switching speed and low latency, making it suitable for testing and measurement applications that require high-speed switching.
Application field:
Automatic Test Equipment (ATE): PXI-2530B can be used for signal switching and routing tasks in ATE systems, such as circuit board testing, electronic component testing, etc.
Automation control system: In an automation environment, this module can be used to control and switch different signal sources, sensors, or actuators to achieve system monitoring and control.
Communication and Radio Testing: PXI-2530B can be used to test and verify the signal switching requirements of communication equipment, radio frequency equipment, and other radio equipment.
Laboratory measurement and research: This module is suitable for measurement and research tasks that require fast switching and routing in a laboratory environment.
In summary, NI PXI-2530B is a high-speed and precise relay module that can be used for signal switching and routing tasks on the PXI platform. It has extensive applications in fields such as automated testing equipment, automated control systems, communication and radio testing, as well as laboratory measurement and research.
2.产 品 展 示
