RELIANCE 57045控制主板卡件
1.产 品 详 情 资 料：
RELIANCE 57045以太网全局数据说明：RX3i固件8.302版有效，CPE310/CPE305 CPU也支持EGD Class 1。在该固件发布之前，EGD仅通过RX3i以太网接口模块（ETM001）在RX3i中可用。与RX3i固件版本8.603一起生效，CPE330还支持EGD Class 1。RELIANCE 57045此功能在RX3i CPE400和RSTi EP CPE100的所有固件版本上都可用。每个PACSystems CPU支持控制器中所有以太网接口上最多255个同时EGD页面。EGD页面必须在编程软件中进行配置并存储到CPU中。EGD配置也可以从CPU加载到编程软件中。生产页面和消费页面都可以进行配置。PACSystems CPU仅支持使用已消耗的EGD页面的一部分，并支持将EGD页面生成和消耗到本地子网的广播IP地址。PACSystems CPU支持2ms EGD页面生成和超时分辨率。EGD页面可以配置为0的生产周期，这表明该页面将在每次输出扫描时生产。这些“尽可能快”页面的最短周期为2毫秒。有关CPE305/310嵌入式以太网接口上的EGD配置，请参阅第A3.6节。在EGD配置期间，PACSystems以太网接口通过其机架/插槽位置进行识别。RELIANCE 57045
Ethernet Global Data Notes: Effective with RX3i Firmware Release 8.302 , the CPE310/CPE305 CPUs also support EGD Class 1. Prior to that firmware release, EGD was only available in the RX3i via the RX3i Ethernet Interface Module (ETM001). Effective with RX3i Firmware Release 8.603 , CPE330 also supports EGD Class 1. This feature is available on all firmware releases of RX3i CPE400 and RSTi-EP CPE100. Each PACSystems CPU supports up to RELIANCE 57045255 simultaneous EGD pages across all Ethernet interfaces in the Controller. EGD pages must be configured in the programming software and stored into the CPU. The EGD configuration can also be loaded from the CPU into the programming software. Both produced and consumed pages can be configured. PACSystems CPUs support the use of only part of a consumed EGD page, and EGD page production and consumption to the broadcast IP address of the local subnet. The PACSystems CPU supports 2ms EGD page production and timeout resolution. EGD pages can be configured for a production period of 0, indicating the page is to be produced every output scan. The minimum period for these “as fast as possible” pages is 2 ms. Refer to the section, A3.6 for EGD configuration on Embedded Ethernet interface of CPE305/310. During EGD configuration, PACSystems Ethernet interfaces are identified by their Rack/Slot location.RELIANCE 57045
2.产 品 展 示
3. 主 营 产 品
