GE V7768-330000处理器模块
1.产 品 详 情 资 料：
类型Satt I/O通信接口电流隔离是状态指示灯正常运行绿色，故障异常红色，COM A/COM B连接器BNC电流消耗（来自CEX总线24 V DC）120 mA典型（最大200 mA）功耗2.9 W典型容量高达3968个二进制I/O通道保护等级IP20，符合EN60529，IEC 529重量700克（1.5磅）（带有CI865和TP865的封装CI865xxx）主要功能•提供一个10/100Mbps快速以太网端口（位于TP867基板上的RJ45连接器）。•提供一个10Mbps以太网端口（位于TP867基板上的RJ45连接器）。•简单的DIN导轨安装。•通过以太网提供与Modbus TCP协议的通信。•安装在机组底座中的预设两个字母的阿尔法代码锁定装置可防止安装不兼容的组件。•支持热插拔。说明CI867/TP867可用于使用Modbus TCP协议将AC 800M控制器连接到外部以太网设备。TP867基板有两个RJ45以太网连接器，其中CH1连接器可以使用10Mbps或100Mbps（兆比特/秒），CH2仅使用10Mbps。基板有一个代码锁（见第75页表4），可防止在TP867基板上安装不正确类型的装置。CI867扩展单元包含CEX总线逻辑、通信单元和DC/DC转换器，该转换器通过CEX总线从+24 V电源提供适当的电压。以太网电缆必须通过以太网交换机连接到主网络。
Type Satt I/O Communication Interface Galvanic isolation Yes Status indicators Run normally green, FAIL exceptionally red, COM A/COM B Connector BNC Current consumption (from CEX-Bus 24 V DC) 120 mA typical (200 mA max.) Power dissipation 2.9 W typical Capacity Up to 3968 binary I/O channels Protection Rating IP20 according to EN60529, IEC 529 Weight 700 g (1.5 lb) (package CI865xxx with CI865 and TP865) Key Features • Provides one 10/100Mbps Fast Ethernet port, (RJ45 connector located on the TP867 Baseplate). • Provides one 10Mbps Ethernet port, (RJ45 connector located on the TP867 Baseplate). • Simple DIN-rail mounting. • Provides communication with Modbus TCP protocol via Ethernet. • Pre-set, two-letter Alpha code locking device installed in unit base prevents mounting of incompatible components. • Supports hot swap. Description The CI867/TP867 can be used to connect an AC 800M controller to external Ethernet devices using Modbus TCP protocol. The TP867 Baseplate has two RJ45 Ethernet connectors, where CH1 connector can use 10Mbps or 100Mbps (Mega bits/sec.) and CH2 use10Mbps only. The baseplate has a code lock (see Table 4 on page 75) that prevents the installation of an incorrect type of unit onto the TP867 Baseplate. The CI867 expansion unit contains the CEX-Bus logic, a communication unit and a DC/DC converter that supplies appropriate voltages from the +24 V supply via the CEX-Bus. The Ethernet cable must be connected to the main network through an Ethernet Switch.
