ABB CI860K01 3BSE032444R1控制系统模块
1.产 品 详 情 资 料：
S100型I/O通信接口电流隔离无状态指示灯正常绿色运行，故障异常红色运行，指示灯TO在S100 I/O访问超时时闪烁黄色。连接器36针中心线微型带状连接器，母型电流消耗（来自CEX总线24 V DC）120 mA典型（最大200 mA）功耗2.9 W典型容量最大5个I/O机架，每个I/O单元的保护等级为IP20，符合EN60529，IEC 529主要特征•提供一个以太网端口（位于TP853基板上的RJ45连接器）。INSUM仅使用COM1。•简单的DIN导轨安装•通过以太网/LON网关提供与INSUM的通信•安装在机组底座中的预设两个字母的Alpha代码锁定装置可防止安装不兼容的组件。•支持热插拔。说明CI857/TP853可用于通过以太网TCP/IP和INSUM TCP/IP网关将AC 800M控制器连接到INSUM，该网关具有与底层INSUM系统通信的LON接口。TP853基板有两个RJ45以太网连接器，但只有COM1连接器用于连接INSUM。底板有一个代码锁，见第75页表4，可防止在TP853底板上安装不正确类型的装置。CI857扩展单元包含CEX总线逻辑、通信单元和DC/DC转换器，该转换器通过CEX总线从+24 V电源提供适当的电压。以太网电缆必须通过以太网交换机连接到主网络。
Type S100 I/O Communication Interface Galvanic isolation No Status indicators Run normally green, FAIL exceptionally red, the indicator TO are yellow flashing at S100 I/O access time-outs. Connector 36 pin centerline miniature ribbon connector, female Current consumption (from CEX-Bus 24 V DC) 120 mA typical (200 mA max.) Power dissipation 2.9 W typical Capacity Max 5 I/O racks with 20 I/O units each Protection Rating IP20 according to EN60529, IEC 529 Key Features • Provides one Ethernet port, (RJ45 connector located on the TP853 Baseplate). Only COM1 is used for INSUM. • Simple DIN-rail mounting • Provides communication with INSUM via Ethernet/LON Gateway • Pre-set, two-letter Alpha code locking device installed in unit base prevents mounting of incompatible components. • Supports Hot swap. Description The CI857/TP853 can be used to connect an AC 800M controller to INSUM through TCP/IP over Ethernet and an INSUM TCP/IP Gateway that has a LON interface communicating with the underlying INSUM system. The TP853 Baseplate has two RJ45 Ethernet connectors, though only the COM1connector is used for connecting to INSUM. The baseplate has a code lock, see Table 4 on page 75, that prevents the installation of an incorrect type of unit onto the TP853 Baseplate. The CI857 expansion unit contains the CEX-Bus logic, a communication unit and a DC/DC converter that supplies appropriate voltages from the +24 V supply via the CEX-Bus. The Ethernet cable must be connected to the main network through an Ethernet Switch.
