HIMA F3231数字量控制板卡
1.产 品 详 情 资 料：
电源输入连接器两针，螺钉连接器L+，L–。电源要求指定为L+和L-24 V标称输入，在19.2 V DC和30 V DC之间变化。电流消耗50 mA（最大70 mA）功耗1.2 W典型保护等级IP20，符合EN60529，IEC 529重量700 g（1.5 lb）（封装BC810K01）尺寸W 59 x H 185 x D 127.5 mm（W 2.9 x H 7.3 x D 5.0 in）主要功能•MPC862P微处理器，运行频率96 MHz。•32 MB RAM•在SIL1-2操作期间提供对PM865控制器的监控。•过电压保护。•内部电压监测。•支持热插拔。•支持冗余。物理描述SM810装置由两部分组成：端接板（TP855）和SM810。SM810包含两个pc板。主板包含MPC862、SDRAM、闪存PROM和CEX总线从接口。子板包含数字I/O，+3.3V电源，带过电压保护和电压监测。端接板包含CEX总线连接器和用于数字I/O的连接器
Power Input Connector Two pin, screw connector L+, L–. Power Supply Requirements Inputs designated L+ and L– 24 V nominal, variation between 19.2 V DC and 30 V DC. Current consumption 50 mA typical (70 mA max) Power dissipation 1.2 W typical Protection Rating IP20 according to EN60529, IEC 529 Weight 700 g (1.5 lb) (package BC810K01) Dimensions W 59 x H 185 x D 127.5 mm (W 2.9 x H 7.3 x D 5.0 in) Key Features • MPC862P Microprocessor running at 96 MHz. • 32 MB RAM • Provides supervision of the PM865 controller during SIL1-2 operations. • Over voltage protection. • Internal voltage monitoring. • Supports hot swap. • Supports redundancy. Description Physically SM810 Unit consists of two parts: Termination Plate (TP855) and SM810. The SM810 contains two pc-boards. The main board contains the MPC862, SDRAM, Flash PROM, and CEX-Bus slave interface. A daughter board contains digital I/O, +3.3V supply with over-voltage protection and voltage monitoring. The termination plate contains CEX-Bus connectors and connectors for the digital I/O
2.产 品 展 示
3.公 司 优 势 主 营 产 品
4.相 关 产 品 展 示
