BENTLY 3500/72M杆位置监控器
1.产 品 介 绍
品牌：BENTLY
型号说明：BENTLY 3500/72M杆位置监控器
优势：供应进口原装正品，专业停产配件。
公司主营特点：主营产品各种模块/卡件，控制器，触摸屏，伺服驱动器。
2.产 品 详 情 资 料：
BENTLY 3500/72M是一款振动监测模块，用于实时监测旋转机械设备的振动和状态。以下是该产品的特点介绍、使用方法和参数规格：
特点介绍：
- 支持多种振动和状态监测方法，包括加速度、速度和位移监测，以及温度、压力、流量等状态监测。
- 可以同时监测多个测点，支持多种传感器类型。
- 采用数字信号处理技术，可实现高精度、高稳定性的振动监测。
- 支持远程控制和数据采集，可与其他监测设备集成。
使用方法：
- 将模块插入BENTLY 3500机架中的一个空闲插槽。
- 连接传感器和其他监测设备，确保连接正确无误。
- 根据需要配置监测参数和报警阈值。
- 启动监测程序，并实时监测振动和状态数据。
- 根据监测数据进行分析和判断，及时采取相应措施。
参数规格：
- 输入电压范围：-10 V 至 +10 V
- 输入频率范围：0 Hz 至 20 kHz
- 最大输入电压：30 Vpk
- 采样率：102.4 kSPS
- 分辨率：24 位
- 连接接口：BNC
- 工作温度范围：0°C 至 50°C
- 工作湿度范围：5% 至 95%，无凝露
- 外形尺寸：3.3 x 16.6 x 24.1 cm
- 重量：约 0.5 kg
总之，BENTLY 3500/72M是一款功能强大、性能稳定的振动监测模块，可广泛应用于工业生产和机械设备维护等领域。
BENTLY 3500/72M is a vibration monitoring module used to monitor the vibration and status of rotating machinery in real time. The following are the features, use methods and parameter specifications of the product:
Features:
Support a variety of vibration and condition monitoring methods, including acceleration, velocity and displacement monitoring, as well as temperature, pressure, flow and other condition monitoring.
It can monitor multiple measuring points at the same time and support multiple sensor types.
Using digital signal processing technology, vibration monitoring with high accuracy and stability can be realized.
It supports remote control and data acquisition and can be integrated with other monitoring equipment.
usage method:
Insert the module into a free slot in the BENTLY 3500 rack.
Connect the sensor and other monitoring equipment to ensure that the connection is correct.
Configure monitoring parameters and alarm thresholds as required.
Start the monitoring program and monitor the vibration and status data in real time.
Analyze and judge according to the monitoring data, and take corresponding measures in time.
Parameter specification:
Input voltage range: - 10 V to+10 V
Input frequency range: 0 Hz to 20 kHz
Maximum input voltage: 30 Vpk
Sampling rate: 102.4 kSPS
Resolution: 24 bits
Connection interface: BNC
Operating temperature range: 0 ° C to 50 ° C
Operating humidity range: 5% to 95%, no condensation
Overall dimensions: 3.3 x 16.6 x 24.1 cm
Weight: about 0.5 kg
In short, BENTLY 3500/72M is a powerful and stable vibration monitoring module, which can be widely used in industrial production, mechanical equipment maintenance and other fields.
3.产 品 展 示
4.公 司 优 势 主 营 产 品
5.相 关 产 品 展 示
