NI PXI-8331接口卡
1.产 品 介 绍
品牌：NI
型号说明：NI PXI-8331接口卡
优势：供应进口原装正品，专业停产配件。
公司主营特点：主营产品各种模块/卡件，控制器，触摸屏，伺服驱动器。
2.产 品 详 情 资 料：
安装PROFINET IO接口CI871 CI871单元由处理器单元通过CEX总线供电，不需要额外的外部电源。安装CI871:1。将CI871装置安装在DIN导轨上。2.将100 Mbps以太网电缆连接到基板上的CH1连接器。3.将以太网电缆的另一端连接到PROFINET IO网络。安装MOD5接口NI PXI-8331单元由处理器单元通过CEX总线供电，不需要任何额外的外部电源。安装CI872:1。将装置安装到DIN导轨上。2.将光纤电缆连接到NI PXI-8331上的CH1、CH2和CH3连接器。将保护插头安装在未使用的端口上。3.将光纤电缆的另一端连接到MOD5控制器。光纤规格以下数据适用于AC 800M控制器和MOD5控制器之间的光纤连接：•波长：820 nm。•光纤尺寸：62.5/125 m多模玻璃光纤。•连接器类型：ST.•最大标称光纤阻尼，包括连接器：11 dB。NI PXI-8331
Installing the PROFINET IO InterfaceNI PXI-8331 unit is powered from the processor unit through the CEX-Bus, which requires no additional external power source. To installNI PXI-8331: 1. Mount the CI871 unit on the DIN-rail. 2. Connect the 100 Mbps Ethernet cable to the CH1 connector on the baseplate. 3. Connect the other end of the Ethernet cable to the PROFINET IO network. Installing the MOD5 Interface CI872 The CI872 unit is powered from the processor unit through the CEX-bus, and does not require any additional external power source. To install NI PXI-8331: 1. Mount the unit onto the DIN-rail. 2. Connect the fiber optic cables to the CH1, CH2, and CH3 connectors on the CI872. Leave the protective plugs mounted on unused ports. 3. Connect the other end of the fiber optic cable to a MOD5 controller. Fiber Optics Specifications The following data applies for the fiber optics connections between the AC 800M controller and MOD5 controllers: • Wavelength: 820 nm. • Fiber size: 62.5/125 m multimode glass fiber. • Connector type: ST. • Max nominal fiber damping including connectors: 11 dB.
3.产 品 展 示
4.公 司 优 势 主 营 产 品
5.相 关 产 品 展 示
本篇文章出自瑞昌明盛自动化设备有限公司官网，转载请附上此链接:http://www.jiangxidcs.com
