WOODWARD 5466-351数字量输入卡件
1.产 品 介 绍
品牌:WOODWARD
型号说明:WWOODWARD 5466-351数字量输入卡件
优势:供应进口原装正品,专业停产配件。
公司主营特点:主营产品各种模块/卡件,控制器,触摸屏,伺服驱动器。
2.产 品 详 情 资 料:
WWOODWARD 5466-351互连完成后,顺时针旋转锁定装置至锁定位置(3)。WWOODWARD 5466-351装置现已完全锁定到位,并与DIN导轨有良好的接地连接。必须将锁定装置放置在锁定位置,以避免振动和/或间歇性接地可能导致的问题。拆除处理器单元连同基板使用以下步骤拆除单元连同基板:1。关闭或断开控制器单元的电源。2.从适当的装置底板上取下任何可拆卸的电缆。图22。WWOODWARD 5466-351-侧视图AC 800M装置在从DIN导轨上拆除之前必须断开电源!不允许在带电运行的系统中操纵CEX总线底板。在更换或移除基板之前,必须移除该段上的所有CEX模块。将锁定装置旋转至装置基板上的滑动位置(2)。为了提供足够的进入和移除空间,请注意,必须在与待移除装置相邻的装置基板上执行滑动顺序。
When the interconnection is complete, rotate the locking device clockwise to the LOCKED position (3). The WWOODWARD 5466-351 unit is now fully locked into the position and has a good ground connection to the DIN-rail. It is essential that the locking device be placed in the LOCKED position to avoid possible problems caused by vibration and/or intermittent grounding.Removing Processor Units Complete with Baseplates Use the following procedure to remove a unit, complete with baseplate: 1. Switch off or disconnect the power supply to the controller units. 2. Remove any detachable cables from the appropriate unit baseplate. Figure 22. WWOODWARD 5466-351 - Side view AC 800M units must be disconnected from the power source before removing them from a DIN-rail! It is not allowed to manipulate CEX bus baseplates in a powered and running system. Before changing or removing a baseplate, all CEX modules on that segment must be removed.Rotate the locking device to the SLIDE position (2) on the unit baseplate,In order to provide adequate access and removal space, note that the SLIDE sequence must be carried out on the unit baseplates adjacent to the unit that is to be removed.
3.产 品 展 示
4.公 司 优 势 主 营 产 品
5.相 关 产 品 展 示
