WOODWARD 5466-061工控DCS系统
1.产 品 介 绍
品牌：WOODWARD
型号说明：WOODWARD 5466-061工控DCS系统
优势：供应进口原装正品，专业停产配件。
公司主营特点：主营产品各种模块/卡件，控制器，触摸屏，伺服驱动器。
2.产 品 详 情 资 料：
WOODWARD 5466-061每个模块的导电背板连接到金属DIN导轨，该导轨用作互连设备之间的模块电子接地导体。这是为了确保模块的内部逻辑以及EMI抗扰度和RF发射的良好接地连接。DIN安装导轨必须与机柜的PE有良好的结合。如果AC 800M模块被配置为两个或多个与延长电缆互连的组，WOODWARD 5466-061应特别注意确保所有组的DIN导轨与接地连接良好。还要确保固定数字。安装在金属板上DIN导轨应每100 mm（4 in）用紧固螺钉牢固地连接到未涂漆的金属板上，以确保机柜或开放式机架中良好的机械稳定性和良好的底盘接地连接。金属板厚度至少应为2.5mm，高度至少为180mm。金属板应至少每隔500 mm用至少WOODWARD 5466-061四个螺钉机械固定在机柜或机架上。机柜框架的紧固应使用自攻螺钉进行，以获得良好的接地连接。
Each module's conductive back plane connects to the metallic DIN-rail which serves as the module electronics ground conductor between the interconnected devices.WOODWARD 5466-061This is to ensure a good ground connection both for the internal logic and for the EMI immunity and RF emission of the modules. The DIN mounting rail must have a good bond to the PE of the cabinet. If AC 800M modules are configured as two or more groups interconnected with extension cables, special care should be taken to ensure that the DIN-rails of all groups have a good connection to ground. Also ensure to fix the figure numbers. Mounting on metal sheet The DIN-rail shall be firmly attached to an unpainted metal sheet with fastening screws every 100 mm (4 in) to ensure good mechanical stability and a good chassis ground connection in the cabinet or an open rack. The metal sheet shall at least be 2.5 mm thick and at least 180 mm high. The metal sheet shall be mechanical fastened at least every 500 mm to the cabinet or rack with a minimum of four screws. The fastening to the cabinet frame shall be performed with self-tapping screws to get a good grounding connection.WOODWARD 5466-061
