RELIANCE 45C410C工控控制卡件
1.产 品 介 绍
品牌：RELIANCE
型号说明：RELIANCE 45C410C工控控制卡件
优势：供应进口原装正品，专业停产配件。
公司主营特点：主营产品各种模块/卡件，控制器，触摸屏，伺服驱动器。
2.产 品 详 情 资 料：
RELIANCE 45C410C注意：在没有可选VMEbus接口（即没有VMEchip2）的控制器上，可以在不影响正常操作的情况下安装或移除跳线。MVME162FX的Z85230串行通信控制器的IMM选择端口B可通过安装在控制器连接器J10上的串行接口模块（SIMM）进行配置。提供五个串行接口模块：❏ EIA-232-D（DCE和DTE）❏ EIA-530（DCE和DTE）❏ EIA-485/EIA-422（DCE或DTE）通过安装适当的串行接口模块，您可以将端口B从EIA-232-D更改为EIA-530接口或EIA-485/IIA-422接口（反之亦然）。端口B（通过J10处的SIMM）连接到标有串行端口2的25针DB25前面板连接器。控制器上SIMM连接器J10的位置见图2-1。RELIANCE 45C410C图2-2显示了串行接口模块的次级（底部）侧，显示了插入控制器上SIMM连接器J10的J1连接器。图2-3（表3-6）、图2-4、图2-5（表3和4）和图2-6说明了端口B可用的九种配置。RELIANCE 45C410C
Note On controllers without the optional VMEbus interface (i.e., no VMEchip2), the jumper may be installed or removed without affecting normal operation.SIMM Selection Port B of the MVME162FX’s Z85230 serial communications controller is configurable via a serial interface module (SIMM) which is installed at connector J10 on the controller. Five serial interface modules are available:RELIANCE 45C410C❏ EIA-232-D (DCE and DTE) ❏ EIA-530 (DCE and DTE) ❏ EIA-485/EIA-422 (DCE or DTE) You can change Port B from an EIA-232-D to an EIA-530 interface or to an EIA-485/EIA-422 interface (or vice-versa) by installing the appropriate serial interface module. Port B is routed (via the SIMM at J10) to the 25- pin DB25 front panel connector marked SERIAL PORT 2. Refer to Figure 2-1 for the location of SIMM connector J10 on the controller. Figure 2-2 illustrates the secondary (bottom) side of a serial interface module, showing the J1 connector which plugs into SIMM connector J10 on the controller. Figure 2-3 (sheets 3-6), Figure 2-4, Figure 2-5 (sheets 3 and 4), and Figure 2-6 illustrate the nine configurations available for Port B.RELIANCE 45C410C
