RELIANCE S-D4008-E模拟I/O卡
1.产 品 介 绍
品牌：RELIANCE
型号说明：RELIANCE S-D4008-E模拟I/O卡
优势：供应进口原装正品，专业停产配件。
公司主营特点：主营产品各种模块/卡件，控制器，触摸屏，伺服驱动器。
2.产 品 详 情 资 料：
RELIANCE S-D4008-E耦合模块退出：1。关闭模块2。拆下模块3的固定螺钉。取出模块。插入：1。插入并固定模块2。打开模块。7.1.3中央模块（CU）和协处理器模块（CM）退出：RELIANCE S-D4008-E1。拧下数据电缆插头的螺钉。2.取出数据电缆并将其弯曲。3.拆下模块的固定螺钉。4.完全抽出固定螺钉直到停止。5.通过弹出杆（标签）将模块与总线板分离，然后将其完全收回。6.请勿触摸模块组件！关注CMOS组件的EMC规则！插入：1。根据数据表检查开关和跳线的设置。2.完全抽出前板的固定螺钉，直到停止。3.将模块插入机架直至停止。4.固定螺钉。5.插入数据电缆并固定其螺钉。RELIANCE S-D4008-E
Coupling Modules Withdraw:RELIANCE S-D4008-E1. Switch off the module 2. Remove fixing screws of the module 3. Withdraw the module. Insert: 1. Insert and fix the module 2. Switch on the module. 7.1.3 Central Module (CU) and Coprocessor Module (CM) Withdraw: 1. Remove the screws of the data cable plugs. 2. Withdraw the data cable and bend it byside. 3. Remove the fixing screws of the module. 4. Withdraw the fixing screws completely till to the stop. 5. Separate the module from the bus board by means of the ejection lever (label) and than withdraw it completely. 6. Do not touch the components of the module! Watch for the EMC rules for CMOS components! Insert: 1. Check the settings of the switches and jumpers according to the data sheet. 2. Withdraw the fixing screws of the frontplate completely till to the stop. 3. Insert module into the rack till to the stop. 4. Fix the screws. 5. Plug in the data cable and fix their screws.RELIANCE S-D4008-E
3.产 品 展 示
4.公 司 优 势 主 营 产 品
5.关 于 相 关 产 品 展 示
