HELMHOLZ 700-872-MDM02控制主板卡件
产品详情资料：
HELMHOLZ 700-872-MDM02控制主板卡件串行端口以太网接口上有两个串行端口：Station Manager端口和Downloader端口。Station Manager端口。此RS-232端口用于连接终端或终端仿真器，以访问以太网接口上的Station Manager软件。此端口使用6针RJ-11连接器。HELMHOLZ 700-872-MDM02 Station Manager电缆非常适合连接到此端口（详细信息请参见第10章）。固件升级端口。15针D型RS-485端口用于连接PC下载器，以防需要更新以太网接口中的通信软件。此连接使用IC690ACC901微型转换器/电缆套件（详见附录E）。AAUI（收发器）端口14针AAUI端口通过IEEE 802.3收发器电缆连接到外部以太网兼容收发器。GE Fanuc产品目录号HELMHOLZ 700-872-MDM02（适用于10Base T）或IC649AEA 103（适用于10 Base2）是合适的收发器（详见附录J）。默认MAC地址标签“默认MAC地址”标签列出了此模块要使用的以太网MAC地址HELMHOLZ 700-872-MDM02
Serial Ports There are two serial ports on the Ethernet Interface: the Station Manager Port and the Downloader Port. The Station Manager Port. This RS-232 port is used to connect a terminal or terminal emulator to access the Station Manager software on the Ethernet Interface. This port uses a 6-pin, RJ-11 connector. The IC693CBL316 Station Manager cable is ideal for connecting to this port (see Chapter 10 for details). The Firmware Upgrade Port. The 15-pin, D-type, RS-485 port is used to connect to the PC Downloader in case the communications software in the Ethernet Interface needs to be updated. Use theHELMHOLZ 700-872-MDM02 miniconverter/cable kit for this connection (see Appendix E for details). AAUI (Transceiver) Port The 14-pin AAUI port connects to an external Ethernet-compatible transceiver via an IEEE 802.3 transceiver cable. GE Fanuc catalog number IHELMHOLZ 700-872-MDM02 (for 10Base T) orHELMHOLZ 700-872-MDM02 (for 10Base2) are suitable transceivers (see Appendix J for details). Default MAC Address Label The Default MAC Address label lists the Ethernet MAC address to be used by this module
品牌：HELMHOLZ
型号：HELMHOLZ 700-872-MDM02
产品说明：控制主板卡件
特点：模块/卡件，控制器，触摸屏，伺服驱动器
优势：供应进口原装正品，专业停产配件。
