ABB IPMON01功率监控模块
品牌：ABB
型号：ABB IPMON01
产品说明：功率监控模块
ABB IPMON01功率监控模块中文资料：
ABB IPMON01功率监控模块嵌入式CPU底板（图3-2和3-3）有三种型号的嵌入式底板，311、313和323。这些型号基于每个型号包含的CPU类型。本章仅讨论这些产品的底板特性。ABB IPMON01嵌入式CPU的CPU规格见第4章。嵌入式CPU基板具有以下特点：ŶCPU类型不能更改。Ŷ它们不支持使用扩展或远程机架，因此这些机架不像模块化CPU底板那样具有扩展连接器。Ŷ由于它们不需要插入式CPU模块，所有编号的插槽（包括插槽1）都可以用于I/O或选件模块。Ŷ内存备用电池位于电源模块中；因此，如果电源从底板上拔下，电池将与位于底板电路板上的存储器电路断开。然而，背板电路板包含一个高值电容器，有时被称为“超级电容器”，如果电源被移除或其电池断开，该电容器可以存储足够的电荷以维持存储器电路约1小时。ABB IPMON01
英文资料
Embedded CPU Baseplates (Figures 3-2 and 3-3) There are three models of embedded baseplates, the 311, 313, and 323. These model numbers are based upon the CPU type that each contains. This chapter discusses only the baseplate features of these products. CPU specifications for the embedded CPU are located in Chapter 4. The embedded CPU baseplates have the following features: Ŷ The CPU type cannot be changed. Ŷ They do not support the use of expansion or remote racks, so these racks do not have an expansion connector like the modular CPU baseplates do. Ŷ The models 311 and 313 are 5-slot baseplates, and the model 323 is a 10-slot baseplate. Ŷ Since they do not require a plug-in CPU module, all numbered slots, including Slot 1, can be used for I/O or Option modules. Ŷ The memory back-up battery is located in the Power Supply module; so if the Power Supply is unplugged from the baseplate, the battery will be disconnected from the memory circuits, which are located on the backplane circuit board. However, the backplane circuit board contains a high value capacitor, sometimes called a ”super capacitor,” that can store enough charge to maintain the memory circuits for about 1 hour if the Power Supply is removed or its battery is disconnected.ABB IPMON01
