ABB INSEM11主传输模块
ABB INSEM11主传输模块中文资料：
ABB INSEM11主传输模块标记模块屏蔽接地连接的孔位置（如果有）。有关说明，请参阅本章中的“模块屏蔽接地”（以及随附章节）。5.完成系统其余部分的铺设（标记孔位置）。这包括您将要使用的任何端子。一些32点I/O模块的DIN导轨式接线板由Weidmuller制造。ABB INSEM11DIN导轨安装的GE Fanuc接线板快速连接（TBQC）组件可用于某些16点和32点离散I/O模块。如果使用这些TBQC，请参考附录H获取数据。此外，APM和DSM模块使用DIN导轨式接线板。注意：我们建议在安装任何组件之前钻孔和攻丝所有孔。这将避免部件中出现碎屑和碎屑。6.钻孔并轻敲标记的孔。对于基板安装，使用8-32或4mm尺寸。7.安装底板。使用质量良好的8-32 x 1/2英寸或4 x 12mm尺寸的螺钉。我们建议在螺钉头下方使用星形锁紧垫圈和平垫圈（星形锁紧垫片应位于螺钉头和平垫圈之间），以确保基板接地连接牢固，并防止螺钉松动。按照本章“基板安全接地”部分所示连接各基板接地线ABB INSEM11
英文资料
Mark the hole locations for module shield ground connections (if any). See “Module Shield Ground” (and accompanying sections) in this chapter for instructions. 5. Finish laying (marking hole locations) out the rest of the system. This includes any terminal blocks you will be using. DIN-rail mounted terminal blocks for some of the 32-point I/O modules are manufactured by Weidmuller. DIN-rail mounted GE Fanuc Terminal Block Quick Connect (TBQC) assemblies are optional for some of the 16-point and 32-point discrete I/O modules. If using these TBQCs, refer to Appendix H for data. Also, APM and DSM modules use DIN-rail mounted terminal blocks. Note We recommend drilling and tapping all holes before mounting any components. This will avoid getting chips and filings in the components. 6. Drill and tap the marked holes. For baseplate mounting, use 8-32 or 4mm size. 7. Mount the baseplates. Use good quality 8-32 x 1/2 inch or 4 x 12mm size screws. We recommend using star lock washers and flat washers under the screw heads (star lock washer should be located between screw head and flat washer) to ensure a tight baseplate ground connection, and to keep the screws from loosening. Connect each baseplate ground wire as shown in the “Baseplate Safety Ground” section of this chapterABB INSEM11
