ABB CI854AK01 3BSE030220R1控制器
ABB CI854AK01 3BSE030220R1控制器中文资料：
ABB CI854AK01 3BSE030220R1控制器标准（IC693PWR321）和大容量（IC693PWR330）AC/DC电源目前都有六个端子用于用户连接。一些90-30系列电源的早期版本有五个端子（参见下图）。五端子和六端子类型的接线方法相似，ABB CI854AK01 3BSE030220R1但以下步骤3不适用于五端子类型。电源端子板将接受一根AWG#14（2.1 mm2）或两根AWG#16（1.3 mm2）75_ C（167_ F）铜线。每个端子都可以接受实心或绞合导线，但任何给定端子中的导线都应为相同类型。电源端子板的建议扭矩为12 in-lbs（1.36牛顿米）。打开保护端子板的门，从交流电源和接地连接（本章稍后将详细介绍系统接地要求）进行以下连接。ABB CI854AK01 3BSE030220R1
英文资料
Both the Standard (IC693PWR321) and High Capacity (IC693PWR330) AC/DC power supplies currently have six terminals for user connections. Early versions of some Series 90-30 power supplies had five terminals (see next figure). The wiring methods for both five-terminal and sixterminal types is similar, except that step 3 below does not apply to the five-terminal type. The power supply terminal boards will accept one AWG #14 (2.1 mm2 ) or two AWG #16 (1.3 mm2 ) copper 75_ C (167_ F) wires. Each terminal can accept solid or stranded wires, but the wires in any given terminal should be the same type. The suggested torque for the power supply terminal board is 12 in-lbs (1.36 Newton-meters). Open the door protecting the terminal board and make the following connections from the AC power source, and ground connections (system grounding requirements are described in detail later in this chapter).ABB CI854AK01 3BSE030220R1
