FOXBORO FBM211 P0914TN输入模块
FOXBORO FBM211 P0914TN输入模块中文资料：
FOXBORO FBM211 P0914TN输入模块组装一个基本的90-30系列PLC系统让我们在纸上组装一个使用以下组件的基本系统：基板电源模块CPU模块一些I/O模块我们将从基板开始。为了保持简单，我们将使用5个插槽大小。注意，5槽底板实际上有6个插槽，但电源插槽没有编号。此外，请注意，该基板有一个CPU插槽，即插槽编号1，并且在右端有一个扩展连接器，如果系统有多个基板，则用于连接到另一个基板。接下来，我们将添加一个电源模块。它安装在基板左端的无编号插槽中。此插槽具有唯一的连接器，只能安装电源模块。然后添加CPU模块。FOXBORO FBM211 P0914TNCPU模块只能安装在靠近电源的基板插槽1中。插槽1有一个唯一的连接器，只能安装CPU或特殊选件模块。CPU331图1-3。CPU模块最后，我们将向基板插槽2到5添加一些I/O模块。要使这个基本系统正常工作，还需要什么？要使这个基本系统正常工作，您需要：安装。将PLC安全、可靠地安装在保护外壳中。接线。这包括正确安装电源的输入电源，以及从I/O模块到现场设备（如开关、传感器、螺线管、继电器等）的接线。PLC运行的应用程序。这是用GE Fanuc PLC编程软件开发的。FOXBORO FBM211 P0914TN
英文资料
Assembling a Basic Series 90-30 PLC System Let’s assemble, on paper, a basic system using the following components: Baseplate Power Supply module CPU module Some I/O modules We’ll start with the baseplate. To keep it simple, we’ll use a 5-slot size. Note that a 5-slot baseplate actually has six slots, but the power supply slot is not numbered. Note also, that this baseplate has a CPU slot, which is slot number 1, and it has an expansion connector on the right end, which is used for connecting to another baseplate if the system has more than one baseplate Next, we’ll add a power supply module. It mounts in the unnumbered slot on the left end of the baseplate. This slot has a unique connector that will only fit a power supply module.Then add a CPU module. A CPU module can only mount in baseplate slot 1, next to the power supply. Slot 1 has a unique connector that will only fit CPU or special Option modules. CPU331 Figure 1-3. CPU Module To finish, we will add some I/O modules to baseplate slots 2 through 5.What else would be needed to make this basic system functional? To make this basic system functional, you would need: Mounting. Safe, secure mounting for the PLC in a protective enclosure. Wiring. This includes properly installed incoming power to the power supply, as well as wiring from the I/O modules to field devices such as switches, sensors, solenoids, relays, etc. Program. An application program for the PLC to run. This is developed with GE Fanuc PLC programming software.FOXBORO FBM211 P0914TN
