ABB AX670 3BSE000566R1模拟模块
ABB AX670 3BSE000566R1目标对象指定目标信号的所有者。目标信号指定连接的目标。目标必须与源的类型相同，并且是子组件的输入或当前组件的输出。允许循环连接允许在同一上下文中设置目标信号两次，否则会生成错误。管理I/O连接管理I/O连接对话框显示组件I/O连接的图形视图。它允许您添加、删除和修改连接。ABB AX670 3BSE000566R1仅显示数字信号。以下控件可用：源/目标信号列出连接中使用的信号，左侧为源信号，右侧为目标信号。每个信号由所有者对象和信号名称指定。连接将连接显示为从源到目标的箭头逻辑门指定逻辑运算符和延迟时间。它对输入信号执行数字逻辑。添加•添加源-向左侧添加源信号。•添加目标-向右侧添加目标信号。•添加逻辑门-在中心添加逻辑门删除所选信号、连接或逻辑门ABB AX670 3BSE000566R1
ABB AX670 3BSE000566R1模拟模块
Target Object Specifies the owner of the target signal. Target Signal Specifies the target of the connection. The target must be of the same type as the source, and either an input to a child component or an output from the current component. Allow cyclic connection Allows the target signal to be set two times in the same context, which would otherwise generate an error.Manage I/O Connections The Manage I/O Connections dialog box displays a graphical view of the I/O connections of the component. It allows you to add, remove, and modify connections. Only digital signals are displayed. The following controls are available:ource / Target Signals Lists the signals used in the connections, source signals to the left and target signals to the right. Each signal is specified by the owner object and the signal name. Connections Displays connections as an arrow from source to target Logic Gates Specifies a logic operator and a delay time. It performs digital logic on input signals. Add • Add Source - Adds a source signal to the left. • Add Target - Adds a target signal to the right. • Add Logic Gate - Adds a logic gate at the center Remove Removes the selected signal, connection or logic gateABB AX670 3BSE000566R1
