可编程07NG20 模块卡件 输入模块机械保护装置
当在例如噪声环境中遇到通信问题或在接近温度极限的情况下工作时，应注意以下建议。操作面板接地1 2 3 4 5 6 5350门操作面板铁氧体磁芯安装板柜内电源24 V DC操作面板的安装夹具未在面板和设备柜之间提供牢固的接地连接，见上图1。1.在操作员面板上的快速连接端子连接器和面板底盘之间连接一根根据当地电气规范正确确定尺寸的电线，参见上图中的2。3BSE069463-600 D版33操作面板接地第7节附加安装提示2。根据当地电气规范，在操作员面板的底盘和最近的接地导线之间连接尺寸正确的导线或接地编织线When experiencing communication problems in for example noisy environments or when operating close to temperature limits, the following recommendations are to be noticed. Grounding the operator panel 1 2 3 4 5 6 5350 Door Operator panel Ferrite core Mounting plate in the cabinet Power supply 24 V DC The mounting clamps of the operator panel do not provide a secure grounding connection between the panel and the device cabinet, see 1 in drawing above. 1. Connect a wire, that is sized correctly according to local electrical codes, between the quick-connect terminal connector on the operator panel and the chassis of the panel, see 2 in drawing above. 3BSE069463-600 Rev D 33 Grounding the operator panel Section 7 Additional Installation Tips 2. Connect a wire or grounding braid, that is sized correctly according to local electrical codes, between the chassis of the operator panel and the closest g
