ABB RF620 3BHT100010R1工控控制卡件
ABB RF620 3BHT100010R1添加实例使用配置编辑器，您可以选择一种类型并创建其新实例。例如，添加Signal类型的新实例会在系统中创建新信号。1.在Offline/Online选项卡中，展开Controller和Configuration节点，然后双击包含要添加实例的类型的主题。这将打开配置编辑器。2.在配置编辑器的类型名称列表中，选择要添加实例的类型。3.在Controller（控制器）菜单上，指向Configuration（配置），然后单击Add type（添加类型）（单词类型将替换为您先前选择的类型）。ABB RF620 3BHT100010R1您也可以右键单击配置编辑器中的任何位置，然后从快捷菜单中选择“添加类型”。ABB RF620 3BHT100010R1将添加一个具有默认值的新实例，并显示在“实例编辑器”窗口中。4.如果需要，编辑值。5.单击“确定”保存新实例ABB RF620 3BHT100010R1
ABB RF620 3BHT100010R1Adding instances
With the Configuration Editor, you can select a type and create a new instance of it. For
example, adding a new instance of the type Signal creates a new signal in the system.
1. In the Offline/Online tab, expand the Controller and the Configuration node and
double-click the topic that contains the type of which you want to add an instance.
This opens the Configuration Editor.
2. In the Type name list of the Configuration Editor, select the type of which you want to
add an instance.
3. On the Controller menu, point to Configuration and click Add type (the word type is
replaced by the type you selected previously).
You can also right-click anywhere in the configuration editor and then select Add type
from the shortcut menu.
A new instance with default values is added and displayed in the Instance Editor
window.
4. If required, edit the values.
5. Click OK to save the new instanceABB RF620 3BHT100010R1
