格式在图形窗口中选择时，指针会捕捉到对象的错误部分。此问题可能由错误的捕捉模式设置、不精确的选择、隐藏或缺少几何信息造成。要解决这些问题，请执行以下操作：•检查选择级别和捕捉模式设置。有关更多信息，请参见第55页的选择项目。•进行选择时，缩放并旋转对象，以确保在对象内部单击。•检查对象是否具有可能影响捕捉的隐藏细节。删除编程或模拟不需要的详细信息。某些文件格式只包含图形表示，不包含几何数据。从包含几何数据的文件格式导入几何图形
ormation
The pointer snaps to the
wrong parts of the objects
when selecting in the
graphics window
This problem might be caused by wrong snap mode settings,
imprecise selecting, hidden or lack of geometrical information.
To resolve these problems, do the following:
• Check the selection level and snap mode settings. For
more information, see Selecting an item on page 55.
• When making the selection, zoom and rotate the object
so that you are sure to click inside the object.
• Check if the object has hidden details that might affect
the snapping. Remove details that are not necessary for
your programming or simulation.Some file formats only contain a graphical representation and no geometrical data. Import the geometry from
a file format that also contains geometrical data
