Vibro-meter 200-595-100-014 200-595-072-122 VM600 CPUM
Control Builder M仅支持1.5 Mbit/s的默认值。通过添加新的CI854/CI854A硬件单元来设置默认值。如果更改波特率，其他参数的当前值将不会更改。如果您还想使这些参数适应新的波特率，则必须手动进行特殊设置对于某些设备，需要对PROFIBUS主参数进行特殊手动调整。RLM01、中继器、MediaConverter如果仅使用一个段或短光纤连接，则无需进行调整。PROFIBUS主参数的自动计算已经考虑到了这一点。如果PROFIBUS由多个段组成或使用长光纤连接，则必须根据供应商提供的值调整设置。光媒体时隙时间（TSL）请参考供应商提供的值。ABB时隙时间（TSL）的链接设备（1）LD 800P将时隙时间增加约150…500
The Control Builder M supports default values only for 1.5 Mbit/s. The default
values are set by adding a new CI854/CI854A hardware unit. If you change the
baudrate the current values for the other parameters will not be changed. If you
also want to adapt these parameters to the new baudrate you have to do it
manually Special Settings
For some devices special manual adjustments to the PROFIBUS master parameters
are necessary.RLM01,
Repeater, MediaConverter
No adjustment is necessary if only one
segment or a short optical connection is
used. The automatic calculation of the
PROFIBUS master parameters has taken
this already into account. If the
PROFIBUS consists of several segments
or long optical connections are used then
the settings have to be adapted to the
values provided by the supplier.
Optical Media Slot time (TSL) Please refer to the values provided by the
supplier.
Linking Device(1)
LD 800P from
ABB
Slot time (TSL) Increase Slot time about 150...500
