Vibro-meter 200-595-031-111 VM600 CPUM模块
要获得PROFIBUS主参数的优化值,请将参数计算方法设置为基于最小值。自动计算现在将重新计算所有参数。结果是您可以为配置的从设备达到最快的循环时间。如果您的设备需要特殊设置,请首先按照上述步骤进行操作。在第二次运行中,对特定参数进行手动调整,将参数计算方法切换为基于实际值,并重复自动计算。默认值在设置PROFIBUS DP-V1波特率时,以下默认值可用作指导。这些值取自PROFIBUS标准,并根据CI854/CI854A的需要进行修改:一些PROFIBUS从设备,如CI830和CI840,与上述参数设置不兼容。在这种情况下,不能使用上述参数。另请参阅您正在使用的PROFIBUS从属类型的文档。
To get the optimized values for the PROFIBUS master parameters set the
parameter Calculation method to Minimum value based. The automatic
calculation will now recalculate all parameters. The result is the fastest possible
cycle time you can reach for the configured slaves.
If you have devices that need special settings then first proceed as described
above. In a second run do the manual adjustments to the specific parameters,
switch the parameter Calculation method to Actual value based and repeat
automatic calculation.Default Values
The following default values may be used as guidelines when setting up the
PROFIBUS DP-V1 baudrate. The values are taken from the PROFIBUS standard
and modified for the CI854/CI854A needs:Some PROFIBUS slave units like CI830 and CI840 are not compatible with the
parameter settings shown above. In such a case, none of the parameters above can
be used. Please see also the documentation for the PROFIBUS slave type you are
using.
