连接选项卡对于CI854/CI854A,可以配置到UnitStatus的连接。有关更多信息,请参阅Control Builder M联机帮助。机组状态选项卡有关机组状态选项卡的信息,请参见Control Builder M在线帮助。PROFIBUS主参数的自动计算定义总线参数的最简单方法是让系统计算它们。您只需将–节点地址、–波特率和–线路冗余模式设置为所需值。无需更改所有其他参数。表3中标有*的参数在下载过程中根据从属装置的实际配置自动计算。自动计算可确保所有计算参数都处于安全状态。这意味着还必须考虑手动更改。因此,不会将实际设置更改为更快但不安全的值。
Connection Tab
For CI854/CI854A a connection to the UnitStatus can be configured. For
more information refer to Control Builder M online help.Unit Status Tab
For information on the Unit Status tab please refer to Control Builder M
online help.
Automatic Calculation of PROFIBUS Master Parameter
The easiest way to define the bus parameters is to let the system calculate them. You
only have to set:
– the node address,
– the baudrate and
– the line redundancy mode
to the required values. All other parameters don’t need to be changed. The
Parameters marked with a * in Table 3 are calculated automatically during
download depending on the actual configuration for the slave units.
The automatic calculation ensures that all calculated parameters will be on the safe
side. This means also manual changes have to be considered. Therefore no changes
of the actual settings in direction to faster but insecure values takes place.
