Vibro-meter 200-510-041-021 200-510-111-021 VM600 MPC4
Min station delay（MinTsdr）响应方可以发送以tbits表示的响应帧之前经过的时间段。然而，从属实现决定了最小响应时间。默认值为11 tbits。将MinTsdr设置得过高可能会降低性能。关闭编辑器窗口时，低于11的设置将被定义的最小值11覆盖。最大站延迟（MaxTsdr）从站响应请求消息的最长时间，以tbits表示。在不同的波特率下，它可能具有不同的值。自动计算可确保主设备中设置的值高于或等于所连接从属设备的最高值。如果没有，将显示警告或错误消息*安静时间（TQUI）发射站在帧结束后必须等待的时间段，然后才能启用其接收器。其目的是在关闭变送器后注意变送器的下降时间。使用自控中继器时，这一点非常重要。
Min station
delay
(MinTsdr)
The period of time which elapses before the responder can send
the response frame expressed in tbits. Slave implementation
determines, however, the minimum response time. The default
value is 11 tbits. Setting MinTsdr too high may slow down the
performance. Settings below 11 will be overwritten with the defined
minimum value 11 when closing the editor window.Max station
delay
(MaxTsdr)
The maximum time the slave is given to respond to a request
message, expressed in tbits. At different baud rates it may have
different values. The automatic calculation ensures that the value
set in the master is higher or equal than the highest value for the
connected slaves. If not, a warning or error message will be
shown.
*Quiet time
(TQUI)
The period of time a transmitting station must wait after the end of
a frame before enabling its receiver. Its purpose is to take care of
transmitter fall time after switching off the transmitter. It is
significant when using self-controlled repeaters.
