EMERSON 1C31177G03环路接口
请注意，单个位置有许多可能的段：偏移地址。上面的公式将提供一个唯一的段：通过将段强制到64 KB的偶数边界，例如$C00、$E000等，来提供偏移地址。使用此公式时，请确保正确舍入偏移计算！简介本章介绍VMIVME-7750的硬件跳线设置、连接器说明、安装、系统设置和操作。开箱程序应遵守运输集装箱中的任何预防措施。所有物品应仔细开箱，并彻底检查运输过程中可能发生的损坏。应检查电路板是否有损坏的组件、损坏的印刷电路板、热损坏和其他可见污染。所有因运输损坏引起的索赔都应提交给承运人，并向VMIC客户服务部发送一份完整的报告，以及一份关于损坏物品处理的建议请求。
Note that there are many possible segment:offset addresses for a single location. The
formula above will provide a unique segment:offset address by forcing the segment to
an even 64 Kbyte boundary, for example, $C000, $E000, etc. When using this formula,
make sure to round the offset calculation properly!Introduction
This chapter describes the hardware jumper settings, connector descriptions,
installation, system setup and operation of the VMIVME-7750.
Unpacking Procedures
Any precautions found in the shipping container should be observed. All items
should be carefully unpacked and thoroughly inspected for damage that might have
occurred during shipment. The board(s) should be checked for broken components,
damaged printed circuit board(s), heat damage and other visible contamination. All
claims arising from shipping damage should be filed with the carrier and a complete
report sent to VMIC Customer Service along with a request for advice concerning the
disposition of the damaged item(s).
