ABB PM571-ETH 1SAP130100R0170系统控制器处理器模块
电路板附件—有关可用变体和附件的完整列表，请参阅MVME7100 SBC的数据表。请参阅附录B相关文档或咨询您当地的SMART EC销售代表以了解其他变体的可用性。概述本章提供与本产品相关的启动和安全说明，包括默认开关设置的硬件准备说明。本章还介绍了基板、PMC和过渡模块的系统注意事项和安装说明。全面实施的MVME7100包括底板和： 两个单宽或一个双宽PCI夹层卡（PMC）插槽，以增加通用性。 一个转换模块，用于支持从MVME7100基板到P2连接器的映射I/O。 最多两个可选的XMCspan卡。下表列出了使用此板之前需要做的事情，并告诉您在哪里可以找到执行每个步骤所需的信息。开始之前，请务必阅读整个章节，包括所有注意和警告注释。
Board Accessories Refer to the data sheets for the MVME7100 SBC for a complete list of available variants and accessories. Refer to Appendix B Related Documentation or consult your local SMART EC sales representative for the availability of other variants.Overview This chapter provides startup and safety instructions related to this product, hardware preparation instruction that includes default switch settings. System considerations and installation instructions for the baseboard, PMC, and transition module are also described in this chapter. A fully implemented MVME7100 consists of the baseboard plus: Two single-wide or one double-wide PCI Mezzanine Card (PMC) slot for added versatility. One transition module for support of the mapped I/O from the MVME7100 baseboard to the P2 connector. Up to two optional XMCspan cards.The following table lists the things you will need to do before you can use this board and tells you where to find the information you need to perform each step. Be sure to read this entire chapter, including all Caution and Warning notes, before you begin.
