RELIANCE 45C364模拟输出
看门狗报警寄存器是寄存器C和D，这些寄存器中存储的信息是BCD格式。时间寄存器寄存器0、1、2、4、6、8、9和A包含BCD格式的时间数据。寄存器0包含两个时间值。位3-0包含0.01秒值，BCD格式的范围为0到9，而位7-4包含0.1秒值，以BCD格式，范围为0至9。此寄存器的总范围为0.00到0.99秒。寄存器1包含两个时间值。位3-0包含1秒值，BCD为0到9，而位7-4包含10秒值，十进制为0到5。此寄存器的总范围为0.0到59.0秒。该寄存器的第7位将始终为零，无论写入的值是什么。
The Watchdog Alarm Registers are Registers C and D, and information stored in these registers is in BCD.Time of Day Registers Registers 0, 1, 2, 4, 6, 8, 9, and A contain Time of Day data in BCD. Register 0 contains two Time of Day values. Bits 3 - 0 contain the 0.01 Seconds value with a range of 0 to 9 in BCD while Bits 7 - 4 contain the 0.1 Seconds value with a range of 0 to 9 in BCD. This register has a total range of 0.00 to 0.99 Seconds. Register 1 contains two Time of Day values. Bits 3 - 0 contain the 1 Seconds value with a range of 0 to 9 in BCD while Bits 7 - 4 contain the 10 Seconds value with a range of 0 to 5 in BCD. This register has a total range of 0.0 to 59.0 Seconds. Bit 7 of this register will always be zero regardless of what value is written to it.
