HIMA F8650X CPU处理器中央模块
在此页面上输入用于配置PQM本身的说明设置。这包括用户首选项、RS485和RS232通信端口、出厂默认值的加载以及用户可编程消息。]]设置点]]S1 PQM设置]首选项]默认消息时间1.0分钟默认消息亮度：60%显示过滤器常数：4默认消息时间：当PQM无人值守时，最多可选择10条默认消息自动按顺序扫描。如果在该设置点设置的默认消息时间内未按下任何键，则当前显示的消息将被第一个默认消息自动覆盖。3秒后，如果选择了多条消息，则显示序列中的下一条默认消息。报警消息始终覆盖默认消息显示。注意，任何设定点或测量值都可以选择为默认消息。
Description Settings to configure the PQM itself are entered on this page. This includes user preferences, the RS485 and RS232 communication ports, loading of factory defaults, and user programmable messages.]] SETPOINTS ]] S1 PQM SETUP ] PREFERENCES ] DEFAULT MESSAGE TIME 1.0 MINUTES DEFAULT MESSAGE BRIGHTNESS: 60% DISPLAY FILTER CONSTANT: 4 DEFAULT MESSAGE TIME: Up to 10 default messages can be selected to automatically scan sequentially when the PQM is left unattended. If no keys are pressed for the default message time set with this setpoint, then the currently displayed message is automatically overwritten by the first default message. After 3 seconds, the next default message in the sequence displays if more than one is selected. Alarm messages always override the default message display. Note that any setpoint or measured value can be selected as a default message.
