HIMA F8652X安全控制系统
PQM出厂时将设定点编程为默认值。这些值显示在所有设定点消息图示中。许多出厂默认值可以保持不变。但是，至少必须输入第21页第4.3.1节：电流/电压配置中阴影部分所示的设定值，系统才能正常工作。为了防止安装未输入设定值的PQM，PQM将报警并锁定，直到输入这些设定值。在PQM用这些临界设定点编程之前，出现“未存储临界设定点”报警信息。]]S1 PQM设置]]设置点]]S2系统设置]]设置值]]S3输出继电器]]设置点]]S4警报/控制]]设置点[]S5测试]首选项]]设置点访问]]COM 1 RS485]串行端口]COM 2 RS485]串口]前面板RS232]串行端口]DNP 3.0]配置
The PQM leaves the factory with setpoints programmed to default values. These values are shown in all the setpoint message illustrations. Many of these factory default values can be left unchanged. At a minimum however, setpoints that are shown shaded in Section 4.3.1: Current/Voltage Configuration on page –21 must be entered for the system to function correctly. In order to safeguard against the installation of a PQM whose setpoints have not been entered, the PQM will alarm and lock out until the values have been entered for these setpoints. The CRITICAL SETPOINTS NOT STORED alarm message is present until the PQM is programmed with these critical setpoints.]] S1 PQM SETUP ]] SETPOINTS ]] S2 SYSTEM SETUP ]] SETPOINTS ]] S3 OUTPUT RELAYS ]] SETPOINTS ]] S4 ALARMS/CONTROL ]] SETPOINTS ]] S5 TESTING ] PREFERENCES ] ] SETPOINT ACCESS ] ] COM 1 RS485 ] SERIAL PORT ] COM 2 RS485 ] SERIAL PORT ] FRONT PANEL RS232 ] SERIAL PORT ] DNP 3.0 ] CONFIGURATION
