HIEE205019R4机械设备卡件
管理器串行端口已替换为前面板以太网端口每个CPU机架最多ETM001模块八个位置PACSystems™ RX3i和RSTi EP TCP/IP以太网通信用户手册第1节GFK-2224Y 2019年8月简介9 1.3.3.1 RX3i嵌入式接口连接器CPE302/CPE305和CPE310：一个RJ45连接器CPE330：三个RJ45连接器CPT400：六个RJ45连接器：五个在前面，用于LAN1、LAN2和LAN3；下面是一个全民教育。（下面还有一个串行RJ45，标记为COM1。）CPL410：六个RJ45连接器：前面五个用于LAN1、LAN2和LAN3；下面有一个ETH。（下面还有一个串行RJ45，标记为COM1。）CPE100/CPE115：四个RJ45连接器LAN IEEE 802.3 CSMA/CD介质访问控制10/100/1000 Mbps CPE302/CPE305和CPE310有一个10Base-T/100Base TX端口（LAN1）CPE330有两个独立的10/100 Mbps以太网LAN：▪ 顶部以太网端口使用专用RJ45连接器连接到LAN1▪ 底部的两个以太网端口使用一对内部交换RJ45连接器连接到LAN2，CPE400支持四个独立的10/100/1000以太网LAN，这些LAN由嵌入式RX3i PLC控制。▪ LAN1通过上部专用RJ45前面板连接器连接。▪ LAN2和LAN31各自通过一对内部交换的RJ45前面板连接器连接。▪ 第四个LAN，标记为EFA（嵌入式现场代理），位于下侧，专门用于现场代理连接。CPL410支持四个独立的10/100/1000以太网LAN，这些LAN由嵌入式RX3i PLC控制。▪ LAN1通过上部专用RJ45前面板连接器连接。▪ LAN2和LAN3分别通过一对内部交换的RJ45前面板连接器连接。第四个局域网，标记为ETH（以太网），位于底层，由嵌入式Linux操作系统控制。CPE100/CPE115支持位于前面板上的两个独立的10/100以太网LAN。▪ LAN1通过上部专用RJ45连接器连接。CPE302/CPE305和CPE310 LAN1的连接：▪ 最多32个SRTP服务器连接，包括：▪ 最多可同时连接16个Modbus/TCP服务器。▪ 最多16个客户端频道。（每个信道可以是SRTP客户端或Modbus/TCP客户端。任何给定信道一次只能分配给一个协议。）▪ OPC UA服务器支持最多5个并发会话，最多10个并发变量订阅和最多12500个变量。▪ 多达255个同时进行的1类以太网全局数据（EGD）交换。对于CPE330、CPE4001和CPL410，嵌入式以太网允许CPU通过以下方式支持LAN1和LAN2：▪ 最多48个同时SRTP服务器连接，以及▪ 最多可同时连接16个Modbus/TCP服务器▪ 最多允许32个客户；每个可以是SRTP或Modbus/TCP▪ OPC UA服务器支持最多5个并发会话，最多10个并发变量订阅，最多12500个变量▪ 多达255个同时进行的1类以太网全局数据（EGD）交换。对于CPE100/CPE115，嵌入式以太网允许CPU通过以下方式支持LAN1和LAN2：▪ 最多可同时连接16个SRTP服务器，以及▪ 最多可同时连接8个Modbus/TCP服务器▪ 最多允许8个客户；每个可以是SRTP或Modbus/TCP▪ 最多8个同时进行的1类以太网全局数据（EGD）交换。Station Manager访问远程UDP有关支持的命令，请参阅《PACSystems TCP/IP以太网通信Station Manager用户手册》GFK-2225J或更高版本。1.3.4以太网接口端口
Manager serial port has been replaced by the front panel Ethernet port Maximum ETM001 Modules per CPU rack Eight positions PACSystems™ RX3i and RSTi-EP TCP/IP Ethernet Communications User Manual Section 1 GFK-2224Y August 2019 Introduction 9 1.3.3.1 RX3i Embedded Interface Connector CPE302/CPE305 & CPE310: One RJ45 connector CPE330: Three RJ45 connectors CPE400: Six RJ45 connectors: five on front for LAN1, LAN2 & LAN3; one EFA on underside. (There is also a serial RJ45 on underside, marked COM1.) CPL410: Six RJ45 connectors: five on front for LAN1, LAN2 & LAN3; one ETH on underside. (There is also a serial RJ45 on underside, marked COM1.) CPE100/CPE115: Four RJ45 connectors LAN IEEE 802.3 CSMA/CD Medium Access Control 10/100/1000 Mbps CPE302/CPE305 & CPE310 has one 10Base-T/100Base-TX Port (LAN1) CPE330 has two independent 10/100 Mbps Ethernet LANs: ▪ The top Ethernet port attaches to LAN1 using a dedicated RJ45 connector ▪ The bottom two Ethernet ports attach to LAN2 using a pair of internallyswitched RJ45 connectors CPE400 supports four independent 10/100/1000 Ethernet LANs which are under the control of the embedded RX3i PLC. ▪ LAN1 attaches via the upper, dedicated RJ45 front-panel connector. ▪ LAN2 and LAN31 each attach via a pair of internally-switched RJ45 frontpanel connectors. ▪ The fourth LAN, labeled EFA (Embedded Field Agent), is located on the underside, and is specifically used for Field Agent connectivity. CPL410 supports four independent 10/100/1000 Ethernet LANs which are under the control of the embedded RX3i PLC. ▪ LAN1 attaches via the upper, dedicated RJ45 front-panel connector. ▪ LAN2 and LAN3 each attach via a pair of internally-switched RJ45 frontpanel connectors. The fourth LAN, labeled ETH (Ethernet), is located on the underside, and is under the control of the embedded Linux Operating System. CPE100/CPE115 supports two independent 10/100 Ethernet LANs located on the front panel. ▪ LAN1 attaches via the upper, dedicated RJ45 connector. connections For CPE302/CPE305 & CPE310 LAN1: ▪ Up to 32 SRTP Server connections, includes: ▪ Up to 16 simultaneous Modbus/TCP Server connections. ▪ Up to 16 Client channels. (Each channel may be an SRTP Client or a Modbus/TCP Client. Any given channel can be assigned to only one protocol at a time.) ▪ OPC UA Server with support for up to 5 concurrent sessions with up to 10 concurrent variable subscriptions and up to 12,500 variables. ▪ Up to 255 simultaneous Class 1 Ethernet Global Data (EGD) exchanges. For CPE330, CPE4001 and CPL410, the embedded Ethernet permits the CPU to support LAN1 and LAN2 with: ▪ Up to 48 simultaneous SRTP Server connections, and ▪ Up to 16 simultaneous Modbus/TCP Server connections ▪ Up to 32 Clients are permitted; each may be SRTP or Modbus/TCP ▪ OPC UA Server with support for up to 5 concurrent sessions with up to 10 concurrent variable subscriptions and up to 12,500 variables ▪ Up to 255 simultaneous Class 1 Ethernet Global Data (EGD) exchanges. For CPE100/CPE115, the embedded Ethernet permits the CPU to support LAN1 and LAN2 with: ▪ Up to 16 simultaneous SRTP Server connections, and ▪ Up to 8 simultaneous Modbus/TCP Server connections ▪ Up to 8 Clients are permitted; each may be SRTP or Modbus/TCP ▪ Up to 8 simultaneous Class 1 Ethernet Global Data (EGD) exchanges. Station Manager Access remote UDP Refer to the PACSystems TCP/IP Ethernet Communications Station Manager User Manual, GFK-2225J or later for supported commands. 1.3.4 Ethernet interface Ports
