HIEE300888R0001 UAC389AE01工控模块卡件
修订版Bxxx：端口号LED（表示端口号的数字由LED背光）红色，仅在端口3和4上：错误，如SFP不兼容。关闭无端口错误。连接链路上的1000速度LED绿色，1000 Mbps绿色闪烁端口处于活动状态，1000 Mbps关闭关联的以太网端口未以1000 Mbps 100速度LED绿色连接到活动链路，连接链路上，100 Mbps。绿色，闪烁端口激活，100 Mbps关闭相关以太网端口未连接到100Mbps 10速LED PACSystems*RX3i系统手册第16节GFK-2314T 2019年9月专用模块783绿色，连接到链路上，10 Mbps。绿色，闪烁端口活动，10 Mbps关闭关联的以太网端口未连接到10Mbps 16.20.3.7 USB LED的活动链路USB LED指示USB端口上的活动（仅限Axxx）。绿色，连接了USB电缆。绿色，闪烁USB端口活动关闭无USB端口活动16.20.4规格：PNS001 PROFINET支持PROFINET 2.3版A类IO设备冗余控制操作符合PROFINET V2.3 S-2型系统冗余。控制器CPU版本要求RX3i CPU315/CPU320，固件版本7.10或更高版本RX3i CPE302/CPE305/CPE310，固件版本为7.10或更新版本RXi控制器，固件版本7.80或更新版本Profice Machine Edition版本要求8.5 SIM2或更高的版本功率要求Rev.–Bxxx或更高：3.3Vdc:0.6A，未安装SFP设备，最大1.3A（安装两个SFP设备，每个SFP 0.35 A）版本–Axxx:3.3 Vdc:1.2A（未安装SFP设备），最大1.9A（安装了两个SFP装置，每个SFP 0.35A）版本-Bxxx或更高版本：5 Vdc:0.7 A最大版本–Axxx：5 Vdc：1.1A最大工作温度范围版本-Bxx或更高：Micro USB连接器。符合USB 2.0标准的全速（12 MHz）SD卡支持SD和SDHC卡。PNS状态和控制位32个输入状态位和32个输出控制位PROFINET I/O生产率（ms）外部端口（包括额外的前面板端口）和一个用于交换端口的内部端口。版本-Axxx:5每个外部端口和一个内部端口各一个。I/O站最大限制每个站的I/O模块数量主机RX3i机架中的背板插槽数量减去PNS001模块本身的插槽数量减去每个站RX3i电源I/O数据占用的插槽数量2880字节总输入数据1440字节输出数据配置V2.3 GSDML文件。该文件包含在Proficy Machine Edition中；可用于导入第三方工具。注意：需要支持GSDML V2.3 MenuList元素的配置软件（如Proficy Machine Edition 8.0或更高版本）来显示大多数IC695xxx I/O模块的配置参数。有关产品标准和一般规范，请参阅附录A。在发布时，需要以下CPU固件、编程软件和背板硬件版本。有关更新信息，请参阅PACSystems RX3i PROFINET扫描仪手册GFK-2737。16.20.5兼容性：PNS001 PACSystems*RX3i系统手册第16节GFK-2314T 2019年9月专用模块785控制器CPU固件CPE400，CPL410，LAN2配置为嵌入式PROFINET控制器。CPU330固件版本8.45或更新版本CPU315/CPU320固件版本7.10或更新版本CPE302/CPE305/CPE310固件版本7.100或更高版本RXi控制器固件版本7.80或更新版本CRU320主固件版本8.00编程器软件Profice Machine Edition版本8.50 SIM 2或更新版本RX3i PROFINET控制器IC695PNC001，固件版本1.20或更高（Simplex I/O）固件版本2.00或更高版本（冗余I/O）RX3i背板硬件必须使用以下最低背板硬件版本：IC695CHS012-BAMP IC695CHS016-BAMP IC69CHS012CA-BAMP IC695CHS016 CA-BAMP或IC695CHS012-CA（或更高）IC695CHS2016-CA（或更晚）IC695CH016CA-CA
Revision Bxxx: Port Number LED (Digit representing Port Number is backlit by an LED) Red, on Port 3 and 4 only: Error such as incompatible SFP. Off No Port error. 1000 Speed LED Green on Link connected, 1000 Mbps Green blinking Port active, 1000 Mbps Off The associated Ethernet port is not connected to an active link at 1000Mbps 100 Speed LED Green, on Link connected, 100 Mbps. Green, blinking Port active, 100 Mbps Off The associated Ethernet port is not connected to an active link at 100Mbps 10 Speed LED PACSystems* RX3i System Manual Section 16 GFK-2314T Sept. 2019 Special Purpose Modules 783 Green, on Link connected, 10 Mbps. Green, blinking Port active, 10 Mbps Off The associated Ethernet port is not connected to an active link at 10Mbps 16.20.3.7 USB LED The USB LED indicates activity on the USB port (-Axxx only). Green, on A USB cable is connected. Green, blinking USB port activity Off No USB port activity 16.20.4 Specifications: PNS001 PROFINET Support PROFINET Version 2.3 Class A IO-Device Redundantly controlled operation conforms to PROFINET V2.3 Type S-2 System Redundancy. Controller CPU Version Required RX3i CPU315/CPU320 with firmware version 7.10 or later RX3i CPE302/CPE305/CPE310 with firmware version 7.10 or later RXi Controller with firmware version 7.80 or later Proficy Machine Edition Version Required Version 8.5 SIM2 or later Power Requirements Rev. –Bxxx or later: 3.3Vdc: 0.6A with no SFP devices installed, 1.3A maximum (two SFP devices installed, 0.35 A per SFP) Rev. –Axxx: 3.3 Vdc: 1.2A with no SFP devices installed, 1.9A maximum (two SFP devices installed, 0.35A per SFP) Rev. –Bxxx or later: 5 Vdc: 0.7 A maximum Rev. –Axxx: 5 Vdc: 1.1A maximum Operating Temperature Range Rev. -Bxxx or later: Micro-USB connector. USB 2.0 compliant running at full-speed (12 MHz) SD Card Supports SD and SDHC cards. PNS Status and Control Bits 32 input status bits and 32 output control bits PROFINET I/O production rate (ms) external port (including additional front panel port) and one internal for switched ports. Rev. -Axxx: 5 One per external port and one internal. I/O Station Maximum Limits Number of I/O Modules per station Number of backplane slots in the host RX3i rack less one for PNS001 module itself less the number of slots occupied by the RX3i power supply I/O data per station 2880 bytes total 1440 bytes of input data 1440 bytes of output data Configuration V2.3 GSDML file. The file is included with Proficy Machine Edition; available for import into 3rd-Party tools. Note: Configuration software that supports GSDML V2.3 MenuList elements (such as Proficy Machine Edition 8.0 or later) is required to display the configuration parameters of most IC695xxx I/O modules. For product standards and general specifications, refer to Appendix A. At the time of publication, the following CPU firmware, programming software and backplane hardware versions are required. Refer to the PACSystems RX3i PROFINET Scanner Manual, GFK-2737, for updated information. 16.20.5 Compatibility: PNS001 PACSystems* RX3i System Manual Section 16 GFK-2314T Sept. 2019 Special Purpose Modules 785 Controller CPU firmware CPE400, CPL410 with LAN2 configured as embedded PROFINET Controller. CPU330 firmware version 8.45 or later CPU315/CPU320 firmware version 7.10 or later CPE302/CPE305/CPE310 firmware version 7.10 or later RXi Controller firmware version 7.80 or later CRU320 Primary Firmware version 8.00 Programmer software Proficy Machine Edition version 8.50 SIM 2 or later RX3i PROFINET Controller IC695PNC001 with firmware version 1.20 or later (Simplex I/O) IC695PNC001 with firmware version 2.00 or later (Redundant I/O) RX3i backplane hardware The following minimum backplane hardware revision must be used: IC695CHS012-BAMP IC695CHS016-BAMP IC695CHS012CA-BAMP IC695CHS016CA-BAMP or IC695CHS012-CA (or later) IC695CHS016-CA (or later) IC695CHS012CA-CA (or later) IC695CHS016CA-CA
