HIEE300888R0002 UAC389AE02模拟量输入模块
LAN96 IEEE 802.2逻辑链路控制I类IEEE 802.3 CSMA/CD介质访问控制10/100/1000 Mbps 96对于CPE400、CPL410、CPE330和CPE100/CPE115，请参阅《PACSystems RX3i和RSTi EP CPU参考手册》（GFK-2222AE或更高版本）中的等效产品规范。PACSystems*RX3i系统手册第16节GFK-2314T 2019年9月专用模块777每个PROFINET控制器的最大I/O内存128 KB组合输入/输出内存注：RSTi EP CPE100CPE115最多支持8个IO设备。组合的输入和输出存储器相当于这8个设备的输入/输出存储器要求。热插拔PNC001–是；嵌入式PROFINET IO控制器–数量CPU状态位32 PROFINET IO设备在PROFINET网络上的数据更新速率可配置：1ms、2ms、4ms、8ms、16ms、32ms、64ms、128ms、256ms和512ms注意：对于CPE100/CPE115，不建议更新速率低于16ms。IP地址数一个MAC地址数PNC001–5。每个外部PROFINET端口一个，内部一个。嵌入式PROFINET IO控制器–1。PACSystems*RX3i系统手册第16节GFK-2314T 2019年9月专用模块778系统最大限制每个RX3i CPU最多4个PNC001 PROFINET控制器。必须位于主CPU机架中。无法在远程节点中找到。CPE330支持一个嵌入式PROFINET控制器加上最多四个PNC001。CPE400、CPL410和CPE100/CPE115支持一个嵌入式PROFINET控制器。由于这些是独立的CPU，它们的硬件配置中不支持任何PNC001。在最大更新间隔下，每个PNC001的IO控制器最多128个IO设备。每个嵌入式PROFINET控制器在最大更新间隔内最多32个（单工）或最多20个（热备用冗余）。每个RSTi EP CPE100/CPE115嵌入式PROFINET控制器最多8个。有关更新间隔较短的限制，请参阅GFK-2571K第3章中的PROFINET控制器加载限制。配置为MRP Manager PNC001时的最大MRP客户端数–63个嵌入式PROFINET控制器–31个嵌入式PROFINET控制器CPE100/CPE11597–每个网络8个IO设备每个网络最多255个单工或255个冗余I/O设备，分布在最多8个I/O控制器上。每个网络支持的实际设备总数取决于拓扑结构。有关详细信息，请参阅GFK-2571K IO设备，每个RX3i CPU最多255个单工或255个冗余I/O设备，分布在最多四个PROFINET控制器上。每个RSTi EP CPU最多98个IO设备，CPE100/CPE115最多8个单工I/O设备。每个网络的IO控制器最多8个输入和输出内存每个IO控制器最多128 KB组合输入和输出存储器注：RSTi EP CPE100/CPE115最多支持8个IO设备，因此组合输入和输入内存相当于8个设备支持的最大输入/输出内存。每个设备的PROFINET插槽数256每个插槽的PROFINET子插槽数256每RX3i CPU的PROFINET模块数2048编程器限制IO控制器数128（32个RX3i处理器目标×每RX3iCPU 4个IO控制器）IO设备数2048（每个网络128个×16个PROFINET网络）设备总数2176（不包括背板、电源或I/O模块）对于产品标准和一般规范，请参阅附录A97固件v9.30有效，CPE100/CPE115支持MRP。98对于激活嵌入式PROFINET的CPE330，可以有五个PROFINET控制器。PACSystems*RX3i系统手册第16节GFK-2314T 2019年9月专用模块779 16.20 PROFINET扫描仪模块：IC695PNS001/IC695PNS101图407:IC695PNSO01-Bxxx PACSystems*RX3i PROFINET扫描仪（PNS）模块，
LAN96 IEEE 802.2 Logical Link Control Class I IEEE 802.3 CSMA/CD Medium Access Control 10/100/1000 Mbps 96 For CPE400, CPL410, CPE330 and CPE100/CPE115, refer to the equivalent product specifications in the PACSystems RX3i and RSTi-EP CPU Reference Manual, (GFK-2222AE or later). PACSystems* RX3i System Manual Section 16 GFK-2314T Sept. 2019 Special Purpose Modules 777 Maximum I/O Memory 128 Kbytes of combined input/output memory per PROFINET Controller Note: RSTi-EP CPE100CPE115 support a maximum of 8 IO Devices. The combined input and output memory is equivalent to the input /output memory requirements of those 8 devices. Hot-swappable PNC001 – Yes; Embedded PROFINET IO-Controller – No. CPU Status Bits 32 PROFINET IO-Device Data Update Rates on the PROFINET Network Configurable: 1ms, 2ms, 4ms, 8ms, 16ms, 32ms, 64ms, 128ms, 256ms and 512ms Note: For CPE100/CPE115, Update Rates below 16ms are not recommended. Number of IP Addresses One Number of MAC Addresses PNC001 – 5. One per external PROFINET port and one internal. Embedded PROFINET IO-Controller – 1. PACSystems* RX3i System Manual Section 16 GFK-2314T Sept. 2019 Special Purpose Modules 778 System Maximum Limits PROFINET Controllers per RX3i CPU Four PNC001 maximum. Must be located in main CPU rack. Cannot be located in a remote node. CPE330 supports one embedded PROFINET Controller plus up to four PNC001. CPE400, CPL410 & CPE100/CPE115 support one embedded PROFINET Controller. Since these are standalone CPUs they do not support any PNC001 in their hardware configuration. IO-Devices per IO-Controller 128 max per PNC001 at maximum update interval. 32 max (simplex) or 20 max (Hot Standby Redundancy) per embedded PROFINET Controller at maximum update interval. 8 max per RSTi-EP CPE100/CPE115 embedded PROFINET Controller. For limits at shorter update intervals, refer to PROFINET Controller Loading Limits in GFK-2571K, Chapter 3. Max MRP Clients when configured as MRP Manager PNC001 – 63 Embedded PROFINET Controller - 31 Embedded PROFINET Controller CPE100/CPE11597 - 8 IO-Devices per Network Maximum of 255 simplex or 255 redundant I/O Devices per network, spread across a maximum of 8 I/O Controllers. The actual total number of devices supported per network depends on the topology. For details, refer to GFK-2571K IO-Devices per RX3i CPU Maximum of 255 simplex or 255 redundant I/O Devices per RX3i CPU, spread across up to four PROFINET Controllers.98 IO-Devices per RSTi-EP CPU Maximum of 8 simplex I/O Devices for CPE100/CPE115. IO-Controllers per Network Eight maximum Input and output memory per IO-Controller Maximum of 128 Kbytes combined input and output memory Note: RSTi-EP CPE100/CPE115 support maximum 8 IO Devices so the combined input and output memory is equivalent to maximum input /output memory supported by 8 devices. Number of PROFINET Slots per device 256 Number of PROFINET Subslots per slot 256 Number of PROFINET Submodules per RX3i CPU 2048 Programmer Limits Number of IO-Controllers 128 (32 RX3i CPU targets × 4 IO-Controllers per RX3i CPU) Number of IO-Devices 2048 (128 per network × 16 PROFINET networks) Total number of devices 2176 (does not include backplanes, power supplies, or I/O modules) For product standards and general specifications, refer to Appendix A. 97 Effective with firmware v9.30, CPE100/CPE115 support MRP. 98 In the case of CPE330, with embedded PROFINET activated, it is possible to have five PROFINET Controllers. PACSystems* RX3i System Manual Section 16 GFK-2314T Sept. 2019 Special Purpose Modules 779 16.20 PROFINET Scanner Module: IC695PNS001/IC695PNS101 Figure 407: IC695PNS001- Bxxx The PACSystems* RX3i PROFINET Scanner (PNS) module,
