§将敏感输入电线远离电气噪声电线，如离散输出和交流电线。这可以通过将I/O模块分组以保持输出模块与敏感输入模块分离来实现。§每个RX3i背板的四个侧面都需要10 cm（4英寸）的间隙空间，用于通风/冷却。§RX3i背板出于热考虑而设计为水平安装。其他安装方向1 10 9 8 7 6 5 2 11 1。RX3i 2。电线槽（电线槽）3。现场设备连接端子块4。电机连接端子排5。电机起动器6。电路板7。电源8。控制变压器9。可熔断断路器或断路器10。控制继电器11。受保护外壳3 4图8：系统布局指南PACSystems*RX3i系统手册第3节GFK-2314T 2019年9月安装21可能会影响系统性能、可靠性和机构批准，因此不建议安装。§对于所有模拟模块，包括RTD和热电偶模块，使用屏蔽电缆连接，屏蔽一端接地（源极）。▪ 2.3外壳RX3i系统及其组件被视为开放式设备[具有用户可能接触到的带电电气部件]，必须安装在保护外壳中，或安装在为提供安全而制造的其他组件中。外壳或组件至少应提供一定程度的保护，以防12mm以下的固体物体（例如手指）。这相当于NEMA/UL 1型外壳或IP20等级（IEC60529），提供至少2级污染环境。当RX3i系统安装在指定为危险区域的区域时，外壳必须是只能使用工具接近的外壳。有关特定产品认证、危险区域认证类型、危险区域警告和ATEX附加外壳要求的参考，请参阅附录A。外壳必须能够充分消散安装在内部的所有组件产生的热量，以防止组件过热。散热也是决定是否需要风扇和空调等外壳冷却选项的一个因素。RX3i背板的所有侧面需要至少102mm（4英寸）的最小空间用于冷却。可能需要额外的空间，这取决于设备在运行过程中产生的热量，或取决于其他PACSystems*RX3i系统手册第3节GFK-2314T 2019年9月安装22的要求，如系统布线的最小弯曲半径。附录B说明了如何计算机柜中RX3i模块和现场设备的散热。2.3.1 RX3i通用背板尺寸和间距*允许冷却通用背板前视图侧面尺寸适用于门关闭的标准模块。侧面尺寸不包括电缆和连接器所需的额外深度。带有扩展高密度接线板（如接线板IC694TBB132）的模块整体深约½英寸（13mm）。图9:RX3i通用背板尺寸和间距PACSystems*RX3i系统手册第3节GFK-2314T 2019年9月安装23 12插槽RX3i专用背板的安装孔与10插槽Series 90-30背板完全匹配，便于升级。背板必须水平安装，如上所述，通过在模块周围提供足够的气流，以满足产品性能和可靠性规范。其他安装方向可能会影响系统性能、可靠性和机构批准，因此不建议使用。图10：不建议垂直安装2.3.2 RX3i串行扩展背板尺寸和间距每个背板都有用于安装在电气面板上的标准连接法兰。PACSystems*RX3i系统手册第3节GFK-2314T 2019年9月安装24*冷却余量5插槽265mm（10.43英寸）10插槽433mm（17.44英寸）5插槽250mm（9.84英寸）10槽428mm（16.85英寸）102mm*。典型的扩展背板正面图安装模块的扩展背板侧面图142mm（5.59in）侧面尺寸适用于门关闭的模块。侧面尺寸不包括
§ Route sensitive input wires away from electrically-noisy wires such as discrete output and AC wiring. This can be facilitated by grouping I/O modules to keep output modules separated from sensitive input modules. § Clearance space of 10 cm (4 in) on all four sides of each RX3i backplane for ventilation/cooling is required. § RX3i backplanes are designed to be mounted horizontally due to thermal considerations. Other mounting orientations 1 10 9 8 7 6 5 2 11 1. RX3i 2. Wireway (Wire Duct) 3. Field device connection terminal block 4. Motor connection terminal block 5. Motor starters 6. Circuit board 7. Power supply 8. Control transformer 9. Fusible disconnect or circuit breaker 10. Control relays 11. Protected enclosure 3 4 Figure 8: System Layout Guidelines PACSystems* RX3i System Manual Section 3 GFK-2314T Sept. 2019 Installation 21 may affect system performance, reliability, and agency approvals, and are therefore not recommended. § Use shielded cable connections with the shield grounded at one end (at source) for all analog modules, including RTD and Thermocouple modules. ▪ 2.3 Enclosures The RX3i system and its components are considered open equipment [having live electrical parts that may be accessible to users] and must be installed in a protective enclosure or incorporated into other assemblies manufactured to provide safety. At a minimum, the enclosure or assemblies shall provide a degree of protection against solid objects up to 12mm (e.g. fingers). This equates to a NEMA/UL Type 1 enclosure or an IP20 rating (IEC60529) providing at least a pollution degree 2 environment. When an RX3i system is installed into an area designated as a Hazardous Area, then the enclosure must be one that is only accessible by use of a tool. Refer to Appendix A for reference to specific product certifications, types of Hazardous Area approvals, Hazardous Area warnings, and additional enclosure requirements with respect to ATEX. The enclosure must be able to adequately dissipate the heat generated by all of the components mounted inside so that no components overheat. Heat dissipation is also a factor in determining the need for enclosure cooling options such as fans and air conditioning. A minimum space of at least 102 mm (4 in) is required on all sides of the RX3i backplane for cooling. Additional space may be required, depending on the amount of heat generated by the equipment during operation, or on other PACSystems* RX3i System Manual Section 3 GFK-2314T Sept. 2019 Installation 22 requirements such as minimum bend radius for system cabling. Appendix B explains how to calculate heat dissipation for RX3i modules and field devices in an enclosure. 2.3.1 RX3i Universal Backplane Dimensions and Spacing * Allowance for cooling Universal Backplane front view Side dimension is for standard modules with doors closed. Side dimension does not include extra depth required for cables and connectors. Modules with Extended High-Density Terminal Blocks (such as Terminal Block IC694TBB132) are approximately ½-inch (13mm) deeper overall. Figure 9: RX3i Universal Backplane Dimensions and Spacing PACSystems* RX3i System Manual Section 3 GFK-2314T Sept. 2019 Installation 23 The mounting holes for the 12-slot RX3i Universal Backplane match the 10-slot Series 90-30 Backplane exactly, for easy upgrades. Backplanes must be mounted horizontally, as represented above, to meet product performance and reliability specifications by providing adequate airflow around the modules. Other mounting orientations may affect system performance, reliability and agency approvals, and are therefore not recommended. Figure 10: Vertical Mounting Not Recommended 2.3.2 RX3i Serial Expansion Backplane Dimensions and Spacing Each backplane has standard attachment flanges for mounting on an electrical panel. PACSystems* RX3i System Manual Section 3 GFK-2314T Sept. 2019 Installation 24 * Allowance for cooling 5-Slot 265mm (10.43in) 10-Slot 433mm (17.44in) 5-Slot 250mm (9.84in) 10-Slot 428mm (16.85in) 102mm * (4.00in) 102mm * (4.00in) 102mm * (4.00in) 90mm (3.54in) 20mm (0.79in) 130mm (5.12in) 102mm * (4.00in) 5.08mm 0.20 dia. typical Expansion Backplane front view Expansion Backplane with modules installed side view 142mm (5.59in) Side dimension is for modules with doors closed. Side dimension does not include extra depth required for
