HONEYWELL TC-RPFS01工控模块备件
块延迟到期后，将监控数字输入。如果在规定的延迟后发生关闭，将发生跳闸。n ASSIGNABLE INPUT 1 n[ENTER]了解更多输入1功能：压力开关报警范围：见上文。以下设定值仅在输入1（4）功能为“压力开关报警”BLOCK PRES.Sw时适用。启动警报：0 s范围：0到5000 s，步长为1（0表示电机停止运行时功能激活）。仅当输入1（4）功能为“压力开关报警”时可见压力开关报警：未锁定范围：锁定，未锁定。仅当输入1（4）功能为“压力开关报警”时才可见，分配报警继电器：报警范围：报警、报警和辅助2、报警和辅2、报警与辅助3、报警与辅3、辅助2、辅助2和辅助3、辅助3。仅当输入1（4）功能为“压力开关报警”压力开关时可见。报警延迟：5.0秒范围：0.1至100.0秒，步长：0.1。仅当输入1（4）功能为“压力开关报警”压力开关时可见。报警事件：关闭范围：打开、关闭。仅当输入1（4）功能为“压力开关报警”n可分配输入1 n[ENTER]了解更多输入1功能：压力开关跳闸范围：见上文。以下设定值仅在输入1（4）功能为“压力开关跳闸”BLOCK PRES.SW时适用。从启动跳闸：0 s范围：0至5000秒。；步骤：1（0表示在电机停止和运行时功能激活）。仅当输入1（4）功能为“压力开关跳闸”时可见，分配跳闸继电器：跳闸范围：跳闸、跳闸和辅助2、跳闸和辅2和辅助3、跳闸和备用3。仅当输入1（4）功能为“压力开关跳闸”压力开关时可见。跳闸延迟：5.0 s范围：0.1至100.0 s，步长0.1。仅当输入1（4）功能为“压力开关跳闸”时，才显示ENTER ESCAPE♥MESSAGE ESCAPE MESSAGE ESCAPE MESSURE ESCAPE MESSAGE ESCAPE MESSION ESCAPE MISSAGE ESCAP MESSAGE MESSAGE ESCAPE ENTER ESCAPE♥信息ESCAPE GE Multilin 469电机管理继电器4-21 4设定点4.4 S3数字输入4 h）振动开关报警路径：设定点为一个可分配的数字输入选择振动开关报警功能，此处显示的设置点消息将跟随分配消息。当电机停止或运行时，将监控数字输入。如果在指定的延迟后发生关闭，将发出警报。i） 振动开关跳闸路径：设定值×S3数字输入×可分配输入1（4）一旦为其中一个可分配数字输入选择了振动开关跳闸功能，此处显示的设定点信息将跟随分配信息。当电机停止或运行时，将监控数字输入。如果在规定的延迟后发生关闭，将发生跳闸。n ASSIGNABLE INPUT 1 n[ENTER]了解更多输入1功能：振动开关报警范围：见上文。以下设定值仅在输入1（4）功能为“振动开关报警”时适用。振动开关警报：未锁定范围：锁定、未锁定。仅当输入1（4）功能为“振动开关报警”时才可见，分配报警继电器：报警范围：报警、报警和辅助2、报警和辅2、报警与辅助3、报警与辅3、辅助2、辅助2和辅助3、辅助3。仅当输入1（4）功能为“振动开关报警”振动开关时可见。报警延迟：5.0 s范围：0.1至100.0 s，步长0.1。仅当输入1（4）功能为“振动开关报警”振动开关时可见。报警事件：关闭范围：打开、关闭。仅当输入1（4）功能为“振动开关报警”n可分配输入1 n[ENTER]了解更多输入1功能：振动开关跳闸范围：见上文。以下设定值仅在输入1（4）功能为“振动开关跳闸”时适用。分配跳闸继电器：跳闸范围：跳闸、跳闸和辅助2、跳闸和辅2和辅3、跳闸和备用3。仅当输入1（4）功能为“振动开关跳闸”振动开关时可见。跳闸延迟：5.0 s范围：0.1至100.0 s，步长0.1。仅当输入1（4）功能为“振动开关跳闸”时才可见，输入ESCAPE（输入ESCAPE）信息ESCAPE MESSAGE ESCAPE信息ESCAPE MESSAGE ESCAPE（输出ESCAPE）信息ESCAP（输入ESCAP（输出ESCAP）信息）4-22 469电机管理继电器GE Multilin 4.4 S3数字输入4设置点4 j）数字计数器路径：设置点×S3数字输入×可分配输入1（1）一旦选择数字计数器功能对于其中一个可分配的数字输入，此处显示的设置点消息将跟随分配消息。通过增加或减少计数器值，将对开关的每次闭合进行计数。当达到某个计数时，可以配置报警。计数器值可在A4维护×通用计数器×数字计数器实际值中查看。要初始化计数器，在此处编程计数器值，然后将S1 469 SETUP（设置）×CLEAR DATA（清除数据）×PRESET DIGITAL counter（预设数字计数器）设定值更改为“Yes（是）”。例如，电容式接近探头可用于感测非磁性单元
After the block delay has expired, the digital input will be monitored. If a closure occurs, after the specified delay, a trip will occur. n ASSIGNABLE INPUT 1 n [ENTER] for more INPUT 1 FUNCTION: Pressure Sw Alarm Range: See above. The following setpoints apply only if INPUT 1(4) FUNCTION is “Pressure Sw Alarm” BLOCK PRES. SW. ALARM FROM START: 0 s Range: 0 to 5000 s in steps of 1 (0 indicates feature is active while motor is stopped as well as running). Only seen if INPUT 1(4) FUNCTION is “Pressure Sw Alarm” PRESSURE SWITCH ALARM: Unlatched Range: Latched, Unlatched. Only seen if INPUT 1(4) FUNCTION is “Pressure Sw Alarm” ASSIGN ALARM RELAYS: Alarm Range: Alarm, Alarm & Auxiliary2, Alarm & Aux2 & Aux3, Alarm & Auxiliary3, Auxiliary2, Aux2 & Aux3, Auxiliary3. Only seen if INPUT 1(4) FUNCTION is “Pressure Sw Alarm” PRESSURE SW. ALARM DELAY: 5.0 s Range: 0.1 to 100.0 sec., step: 0.1. Only seen if INPUT 1(4) FUNCTION is “Pressure Sw Alarm” PRESSURE SW. ALARM EVENTS: Off Range: On, Off. Only seen if INPUT 1(4) FUNCTION is “Pressure Sw Alarm” n ASSIGNABLE INPUT 1 n [ENTER] for more INPUT 1 FUNCTION: Pressure Switch Trip Range: See above. The following setpoints apply only if INPUT 1(4) FUNCTION is “Pressure Switch Trip” BLOCK PRES. SW. TRIP FROM START: 0 s Range: 0 to 5000 sec.; step: 1 (0 indicates feature is active while motor is stopped as well as running). Only seen if INPUT 1(4) FUNCTION is “Pressure Switch Trip” ASSIGN TRIP RELAYS: Trip Range: Trip, Trip & Auxiliary2, Trip & Aux2 & Aux3, Trip & Auxiliary3. Only seen if INPUT 1(4) FUNCTION is “Pressure Switch Trip” PRESSURE SW. TRIP DELAY: 5.0 s Range: 0.1 to 100.0 s in steps of 0.1. Only seen if INPUT 1(4) FUNCTION is “Pressure Switch Trip” ENTER ESCAPE ð ð MESSAGE ESCAPE MESSAGE ESCAPE MESSAGE ESCAPE MESSAGE ESCAPE MESSAGE ESCAPE ENTER ESCAPE ð ð MESSAGE ESCAPE MESSAGE ESCAPE MESSAGE ESCAPE GE Multilin 469 Motor Management Relay 4-21 4 SETPOINTS 4.4 S3 DIGITAL INPUTS 4 h) VIBRATION SWITCH ALARM PATH: SETPOINTS Õ× S3 DIGITAL INPUTS Õ× ASSIGNABLE INPUT 1(4) Once the Vibration Switch Alarm function is chosen for one of the assignable digital inputs, the setpoint messages shown here will follow the assignment message. When the motor is stopped or running, the digital input will be monitored. If a closure occurs, after the specified delay, an alarm will occur. i) VIBRATION SWITCH TRIP PATH: SETPOINTS Õ× S3 DIGITAL INPUTS Õ× ASSIGNABLE INPUT 1(4) Once the Vibration Switch Trip function is chosen for one of the assignable digital inputs, the setpoint messages shown here will follow the assignment message. When the motor is stopped or running, the digital input will be monitored. If a closure occurs, after the specified delay, a trip will occur. n ASSIGNABLE INPUT 1 n [ENTER] for more INPUT 1 FUNCTION: Vibration Sw Alarm Range: See above. The following setpoints apply only if INPUT 1(4) FUNCTION is “Vibration Sw Alarm”. VIBRATION SWITCH ALARM: Unlatched Range: Latched, Unlatched. Only seen if INPUT 1(4) FUNCTION is “Vibration Sw Alarm” ASSIGN ALARM RELAYS: Alarm Range: Alarm, Alarm & Auxiliary2, Alarm & Aux2 & Aux3, Alarm & Auxiliary3, Auxiliary2, Aux2 & Aux3, Auxiliary3. Only seen if INPUT 1(4) FUNCTION is “Vibration Sw Alarm” VIBRATION SW. ALARM DELAY: 5.0 s Range: 0.1 to 100.0 s in steps of 0.1. Only seen if INPUT 1(4) FUNCTION is “Vibration Sw Alarm” VIBRATION SW. ALARM EVENTS: Off Range: On, Off. Only seen if INPUT 1(4) FUNCTION is “Vibration Sw Alarm” n ASSIGNABLE INPUT 1 n [ENTER] for more INPUT 1 FUNCTION: Vibration Sw Trip Range: See above. The following setpoints apply only if INPUT 1(4) FUNCTION is “Vibration Sw Trip”. ASSIGN TRIP RELAYS: Trip Range: Trip, Trip & Auxiliary2, Trip & Aux2 & Aux3, Trip & Auxiliary3. Only seen if INPUT 1(4) FUNCTION is “Vibration Sw Trip” VIBRATION SW. TRIP DELAY: 5.0 s Range: 0.1 to 100.0 s in steps of 0.1. Only seen if INPUT 1(4) FUNCTION is “Vibration Sw Trip” ENTER ESCAPE ð ð MESSAGE ESCAPE MESSAGE ESCAPE MESSAGE ESCAPE MESSAGE ESCAPE ENTER ESCAPE ð ð MESSAGE ESCAPE MESSAGE ESCAPE 4-22 469 Motor Management Relay GE Multilin 4.4 S3 DIGITAL INPUTS 4 SETPOINTS 4 j) DIGITAL COUNTER PATH: SETPOINTS Õ× S3 DIGITAL INPUTS Õ× ASSIGNABLE INPUT 1(4) Once the Digital Counter function is chosen for one of the assignable digital inputs, the setpoint messages shown here will follow the assignment message. Each closure of the switch will be counted, by either adding or decrementing the counter value. An alarm may be configured when a certain count is reached. The counter value may be viewed in the A4 MAINTENANCE Õ× GENERAL COUNTERS Õ× DIGITAL COUNTER actual value. To initialize the counter, program the counter value here and then change the S1 469 SETUP Õ× CLEAR DATA Õ× PRESET DIGITAL COUNTER setpoint to "Yes". For example, a capacitive proximity probe may be used to sense non-magnetic units
