IS200BPIIH1 IS200BPIIH1AAA机器人模块卡件
将新的8系列改装底盘插入开关设备，只需插入旧的接线板即可-需要进行任何断路修改或推拉电缆。现有SR接线板可轻松插入工厂接线的SR接线板框架，以确保将SR接线板位置映射到8系列接线板8系列保护继电器（与现有SR 469设备匹配）3“减深套环，以确保继电器深度与之前安装的SR设备紧密匹配，无需推拉电缆Multilin 8系列改装：解决方案浏览器应用程序更新设置文件更换继电器即插即用重新连接1 2 3 469电机保护系统8 GEGridSolutions.com典型接线C A B B C电路com 9技术规格输入相电流输入CT主级：1至5000 A CT辅级：1 A或5 A（必须随订单指定）负载：额定负载下小于0.2 VA转换范围：0.05至20 x CT标称频率：20-70 Hz频率范围：20-120 Hz精度：在<2 x CT时：2 x CT的±0.5%在>2 x CT：20 x CT的？%耐受：在80 x额定电流时1秒在40 x额定电流下2秒连续在3 x额定电流差动电流输入CT初级：1至5000 A CT次级：1 A或5 A（设定值）负载：额定负载下小于0.2 VA转换范围：0.02至1 x CT一次电流额定频率：20-70 Hz频率范围：20-120 Hz精度：5 A时1 x CT的±0.5%1 A时5 x CT的0.5%耐受时间：80 x额定电流时1秒40 x额定电流下2秒3 x额定电流连续3 x额定电压下2秒接地电流输入CT一次：1至5000 A CT次级：1 A或5 A（设定值）负载：额定负载下1 A时<0.2 VA或额定负载下5 A时<0.25 VA 25 A时转换范围：0.02至1 x CT初级电流额定频率：20-70 Hz频率范围：20-120 Hz准确度：1 x CT的±0.5%5 x CT（5 A时）±0.125 A（50时）：0.025 CT耐受时间：80 x额定电流时1秒，40 x额定电流下2秒，3 x额定电流电压输入VT比率：1.00至150.00:1，步长为0.01 VT次级：273 V AC（满量程）转换范围：0.05至1.00 x满量程标称频率：20-70 Hz频率范围：20-120 Hz精度：满量程的±0.5%最大连续：280 V AC负载：>500 k数字输入：9个光隔离输入外部开关：干触点<400，或来自传感器的开路集电极NPN晶体管；在24 V DC时，从内部4 K上拉产生6 mA电流，Vce<4 V DC 469传感器电源：+24 V DC，最大20 mA RTD输入3线RTD类型：100铂（DIN.43760）、100镍、120镍、，10铜RTD传感5mA电流：隔离：36 Vpk（与模拟输入和输出隔离）范围：-50至+250°C精度：±2°C导线电阻：Pt和Ni型每根导线25最大值，Cu型每根最大值无传感器：>1000短路/低报警：：<–50°C跳闸线圈监控适用电压：20至300 V DC/V AC涓流电流：2至5 mA模拟电流输入电流输入：0至1mA、0至20mA或4至20 mA（设定值）输入阻抗：226±10%转换范围：0至21 mA精度：满量程的±1%类型：无源模拟输入电源：+24 V DC，100 mA最大响应
Insert the new 8 Series Retrofit chassis into the switchgear and simply plug-in the old terminal blocks - there is need to make any cut-out modifications or push and pull cables. Existing SR Terminal Blocks easily plug-in Factory wired SR Terminal Block Frame to ensure mapping of SR terminal locations to the 8 Series terminal block 8 Series Protection Relay (matched to existing SR 469 device) 3” Depth Reduction Collar to ensure relay depth closely matches the previously installed SR device, eliminating the need to push or pull cables Multilin 8 Series Retrofit: Solutions Explorer Application Update Settings File Replace Relay Plug & Play Reconnection 1 2 3 469 Motor Protection System 8 GEGridSolutions.com Typical Wiring C A B A B C CIRCUIT com 9 Technical Specifications INPUTS PHASE CURRENT INPUTS CT Primary: 1 to 5000 A CT Secondary: 1 A or 5 A (must be specified with order) Burden: Less than 0.2 VA at rated load Conversion Range: 0.05 to 20 x CT Nominal Frequency: 20 - 70 Hz Frequency Range: 20 - 120 Hz Accuracy: at < 2 x CT: ± 0.5% of 2 x CT at > 2 x CT: ± 1% of 20 x CT CT Withstand: 1 second at 80 x rated current 2 seconds at 40 x rated current continuous at 3 x rated current DIFFERENTIAL CURRENT INPUTS CT Primary: 1 to 5000 A CT Secondary: 1 A or 5 A (Set point) Burden: Less than 0.2 VA at rated load Conversion Range: 0.02 to 1 x CT primary Amps Nominal Frequency: 20 - 70 Hz Frequency Range: 20 - 120 Hz Accuracy: ± 0.5% of 1 x CT for 5 A ± 0.5% of 5 x CT for 1 A CT Withstand: 1 second at 80 x rated current 2 seconds at 40 x rated current continuous at 3 x rated current continuous at 3 x rated current GROUND CURRENT INPUTS CT Primary: 1 to 5000 A CT Secondary: 1 A or 5 A (Set point) Burden: < 0.2 VA at rated load for 1 A or 5 A < 0.25 VA for 50:025 at 25 A Conversion Range: 0.02 to 1 x CT primary Amps Nominal Frequency: 20 - 70 Hz Frequency Range: 20 - 120 Hz Accuracy: ± 0.5% of 1 x CT for 5 A ± 0.5% of 5 x CT for 1 A ± 0.125 A for 50:0.025 CT Withstand: 1 second at 80 x rated current 2 seconds at 40 x rated current continuous at 3 x rated current VOLTAGE INPUTS VT Ratio: 1.00 to 150.00:1 in steps of 0.01 VT Secondary: 273 V AC (full scale) Conversion Range: 0.05 to 1.00 x full scale Nominal Frequency: 20 - 70 Hz Frequency Range: 20 - 120 Hz Accuracy: ±0.5% of full scale Max. Continuous: 280 V AC Burden: > 500 k DIGITAL INPUTS Inputs: 9 opto-isolated inputs External Switch: dry contact < 400 , or open collector NPN transistor from sensor; 6 mA sinking from internal 4 K pull-up at 24 V DC with Vce < 4 V DC 469 Sensor Supply: +24 V DC at 20 mA maximum RTD INPUTS 3 wire RTD Types: 100 Platinum (DIN.43760), 100 Nickel, 120 Nickel, 10 Copper RTD Sensing 5mA Current: Isolation: 36 Vpk (isolated with analog inputs and outputs) Range: –50 to +250°C Accuracy: ±2°C Lead Resistance: 25 Max per lead for Pt and Ni type 3 Max per lead for Cu type No Sensor: >1000 Short/Low Alarm:: < –50°C TRIP COIL SUPERVISION Applicable Voltage: 20 to 300 V DC / V AC Trickle Current: 2 to 5 mA ANALOG CURRENT INPUTS Current Inputs: 0 to 1 mA, 0 to 20mA or 4 to 20 mA (setpoint) Input Impedance: 226 ±10% Conversion Range: 0 to 21 mA Accuracy: ±1% of full scale Type: passive Analog In Supply: +24 V DC at 100 mA maximum Response
