IS200HFPAG2ADC工控模块机器人备件
状态指示器：每个点的负载警报负载状态指示器：模块状态通过，故障，激活点隔离1500 VDC，最小逻辑功率<15瓦关闭状态下的短路检测阈值2<24Ω，安装二次现场电源二次电源电压范围5.00 VDC±0.25 VDC二次电源电流范围最小3安培数字输出模块109 Tricon v9–v10系统规划和安装指南3614E规格本表列出了3614E型号的规格，其为TMR监控数字输出模块，标称范围为24 VDC。注：3614E型不建议与并联二极管本质安全栅一起使用。对于这些应用，Triconex推荐3615E型。切换功率切换无功负载时，应将输出的切换功率降到最大值的25%，即直流应用的37.5瓦。当切换白炽灯时，涌入电流可以是灯的额定额定负载电流的10至15倍。有关涌入幅度和持续时间的详细规范，请联系灯具制造商。在计算所需的输出开关功率时，必须使用涌入电流。输出诊断故障范围3：最大输出切换率最小输出切换率每100毫秒加一次扫描不适用开启状态电压降：使用外部终端，10英尺电缆<2 VDC典型@100mA<4 VDC最大@0.5A开启状态电压下降：使用外部端接，99英尺电缆<3 VDC典型@100mA<6 VDC最大@0.5A感应反冲保护（反EMF）终端面板1上的反向二极管。只有遵守所有安装指南和限制条件，才能确保该模块正常运行。有关更多信息，请参阅IPS全球客户支持（GCS）中心提供的应用程序注释8“受监控的数字输出模块”。2.要选择SDO模块的短路检测，TriStation项目的硬件配置中必须包含包含缩写SCD的模块名称。3.最大输出切换率允许正确操作I/O诊断和检测所有正常可检测的故障。最小切换率提供了模块计算平均故障间隔时间（MTBF）10%内正常不可检测故障的故障覆盖率。表40 3614E监控数字输出规格特性规格颜色代码绿松石绿输出信号数量8，公共电压范围20至36 VDC载流额定值，最大0.5安培/点，4安培浪涌/10 ms开关电源，最大值参见第109页的开关功率150瓦（电阻）表39 3613E监控数字输出规格（续）功能规格110第2章Tricon v9–v10系统的系统组件规划和安装指南最大输出循环率<每秒20次最大额定负载下的预期寿命>10000次最小所需负载1 50 mA负载泄漏电流（关闭状态，无辅助电源）最大4 mA现场终端模块上的主保险丝（每个输出2个）0.5安培，现场终端模块（每个输出两个）上的快速作用辅助保险丝0.125安培，快速作用状态指示器：每个点的开或关状态点状态指示器：每点的电源报警电源状态指示器：，有源点隔离1500 VDC，最小逻辑功率<15瓦关闭状态下短路检测2<24Ω，安装二次现场电源二次电源电压范围2 5.00 VDC±0.25 VDC二次电源电流范围3安培，最小输出诊断故障覆盖率3：最大输出切换率最小输出切换率每100毫秒加一次扫描不适用开启状态电压降：使用外部终端，10英尺电缆<2 VDC典型@100mA<4 VDC最大@0.5A开启状态电压下降：使用外部端接，99英尺电缆<3 VDC典型@100mA<6 VDC最大@0.5A感应反冲保护（反EMF）终端面板1上的反向二极管。只有遵守所有安装指南和限制条件，才能确保该模块正常运行。有关更多信息，请参阅IPS全球客户支持网站上的应用程序注释8“受监控的数字输出模块”，网址为http://support.ips.invensys.com.
Status indicator: Load alarm per point Load Status indicator: Module status Pass, Fault, Active Point isolation 1500 VDC, minimum Logic power < 15 watts Short-circuit detection threshold in Off state2 < 24 Ω, with installation of secondary field power supply Voltage range of secondary power supply 5.00 VDC ± 0.25 VDC Current range of secondary power supply 3 amps minimum Digital Output Modules 109 Planning and Installation Guide for Tricon v9–v10 Systems 3614E Specifications This table lists the specifications for model 3614E, which is a TMR Supervised Digital Output Module with a nominal range of 24 VDC. Note The model 3614E is not recommended for use with shunt-diode intrinsic safety barriers. For these applications, Triconex recommends the model 3615E. Switching Power When switching reactive loads, you should de-rate the switching power of the outputs to 25 percent of maximum, which is 37.5 watts for DC applications. When switching incandescent lamps, the inrush current can be 10 to 15 times the rated nominal load current of the lamp. For detailed specifications regarding inrush amplitude and duration, contact the lamp manufacturer. The inrush current must be used when calculating the required output switching power. Output diagnostic fault coverage3: Maximum output toggle rate Minimum output toggle rate Every 100 ms plus one scan Not applicable On-state voltage drop: With external termination, 10-foot cable < 2 VDC typical @ 100mA < 4 VDC maximum @ 0.5A On-state voltage drop: With external termination, 99-foot cable < 3 VDC typical @ 100mA < 6 VDC maximum @ 0.5A Inductive kick-back protection (reverse EMF) Reverse diode on termination panel 1. Proper operation of this module can be assured only if all installation guidelines and restrictions are observed. For more information, see Application Note 8, Supervised Digital Output Modules available from the IPS Global Client Support (GCS) center. 2. To select short-circuit detection for an SDO module, a module name which includes the abbreviation SCD must be included in the hardware configuration in the TriStation project. 3. The maximum output toggle rate allows proper operation of I/O diagnostics and detection of all normally detectable faults. The minimum toggle rate provides fault coverage of normally undetectable faults within 10% of the calculated mean-time-between-faults (MTBF) for the module. Table 40 3614E Supervised Digital Output Specifications Feature Specification Color code Turquoise green Number of output signals 8, commoned Voltage range 20 to 36 VDC Carry current ratings, maximum 0.5 amps/point, 4 amps surge/10 ms Switching power, maximum See Switching Power on page 109 150 watts (resistive) Table 39 3613E Supervised Digital Output Specifications (continued) Feature Specification 110 Chapter 2 System Components Planning and Installation Guide for Tricon v9–v10 Systems Maximum output cycle rate < 20 cycles per second Expected life at maximum rated load > 10,000 cycles Minimum required load1 50 mA Leakage current to load (Off state, without secondary power supply) 4 mA maximum Primary fuse on field termination module (2 per output) 0.5 amp, fast-acting Secondary fuse on field termination module (2 per output) 0.125 amp, fast-acting Status indicator: On or Off state per point Point Status indicator: Power alarm per point Power Status indicator: Load alarm per point Load Status indicator: Module status Pass, Fault, Active Point isolation 1500 VDC, minimum Logic power < 15 watts Short-circuit detection in Off state2 < 24 Ω, with installation of secondary field power supply Voltage range of secondary power supply2 5.00 VDC ± 0.25 VDC Current range of secondary power supply 3 amps, minimum Output diagnostic fault coverage3: Maximum output toggle rate Minimum output toggle rate Every 100 ms plus one scan Not applicable On-state voltage drop: With external termination, 10-foot cable < 2 VDC typical @ 100mA < 4 VDC maximum @ 0.5A On-state voltage drop: With external termination, 99-foot cable < 3 VDC typical @ 100mA < 6 VDC maximum @ 0.5A Inductive kick-back protection (reverse EMF) Reverse diode on termination panel 1. Proper operation of this module can be assured only if all installation guidelines and restrictions are observed. For more information, see Application Note 8, Supervised Digital Output Modules available on the IPS Global Client Support Web Site at http://support.ips.invensys.com.
