IS200HFPRG1A模块卡件,脉冲输入卡件
@ 2A导通状态压降：带外部终端，99英尺电缆<6 VDC，典型@500mA<11 VDC，最大@2A感应反冲保护（反EMF）I/O模块1上的反向二极管。必须向所有点供电，包括非公用面板上未使用的点。2.最大输出切换率可实现I/O诊断的正确操作和所有正常可检测故障的检测。最小切换率提供了模块计算平均故障间隔时间（MTBF）10%内正常不可检测故障的故障覆盖率。3.可使用OVD禁用功能禁用诊断故障。表35 3607E数字输出规格特性规格颜色代码浅蓝色输出信号数量16，非公共电压范围44–80 VDC逻辑功率<10瓦额定电流，最大1安培/点，5安培浪涌/10毫秒负载泄漏电流2 mA，最大保险丝（现场终端模块）每个输出1个（1.25安培快速作用）状态指示器：开或关状态每个点1个状态指示器：模块状态通过、故障、，活动状态指示灯：现场警报1负载/保险丝点隔离最小1500 VDC输出诊断故障覆盖范围2：最大输出切换率最小输出切换率每100 ms不适用诊断故障持续时间3最大2 ms，500μs典型导通状态电压降：在背板上，典型值<2 VDC@250mA<3 VDC最大值@1A导通状态压降：带外部终端，10英尺电缆<3 VDC典型@250mA<4 VDC最大@1A表34 3604E数字输出规格（续）功能规格98第2章Tricon v9–v10系统24至120 VDC监控数字输出模块的系统组件规划和安装指南此图为3623、3623T和3624型（TMR监控数字输出模件）的简化示意图。图40 3623、3623T和3624简化的导通状态压降示意图：带外部终端，99英尺电缆<4 VDC，典型@250mA<7 VDC，最大@1A感应反冲保护（反EMF），输入/输出模块1上的反向二极管。必须向所有点供电，包括非公用面板上未使用的点。2.最大输出切换率可实现I/O诊断的正确操作和所有正常可检测故障的检测。最小切换率提供了模块计算平均故障间隔时间（MTBF）10%内正常不可检测故障的故障覆盖率。3.可使用OVD禁用功能禁用诊断故障。表35 3607E数字输出规格（续）特征规格总线Xcvr点寄存器总线Xcvr点寄存器总线Xcvr点寄存器输出开关驱动电路A A和B输出开关驱动回路输出开关驱动线路B输出开关电路C A B C A和B A B B C+V A B C TRIPLICATED I/O总线现场电路典型点（16）–环回检测器LDRTN智能I/O控制器***所有输出开关都是光隔离的。到其他点到其他点Loopback De et torµProcµProc数字输出模块99 Tricon v9–v10系统规划和安装指南此图显示了3623、3623T和3624型号的前面板。图41 Tricon v9–v10系统3623和3623T规格的组件规划和安装指南本表列出了3623和3613T型号的规格，它们是标称电压为120 VDC的TMR监控数字输出模块。3623型具有1500 VDC的点隔离；3623T型具有2500 VDC的点隔离。小心Triconex强烈建议您在选择3623T型模块用于具有以下任何一项的应用之前进行兼容性测试：•现场布线长度超过328英尺（100米）•非双绞线电缆•非典型负载，如智能设备、闪光灯、，或klaxons表36 3623和3623T监控数字输出规格功能规格颜色代码钢蓝色输出信号数量16，通用推荐电压范围90–150 VDC最大电压160 VDC逻辑功率<10瓦额定电流，最大0.8安培/点，4安培浪涌/10 ms最小所需负载30 mA负载漏电流4 mA，最大保险丝（现场终端）每个输出1个（1安培，快速动作）状态指示器：开或关状态每个点1个状态指示器：模块状态通过、故障、活动状态指示器：现场警报1电源、负载/保险丝（每个点1条）点隔离：3623 1500 VDC最小点隔离：关闭状态下3623T 2500 VDC最小短路检测阈值<24Ω输出诊断故障覆盖范围
@ 2A On-state voltage drop: With external termination, 99-foot cable < 6 VDC typical @ 500mA < 11 VDC maximum @ 2A Inductive kick-back protection (reverse EMF) Reverse diode on I/O module 1. Power must be supplied to all points, including unused points on non-commoned panels. 2. The maximum output toggle rate enables proper operation of I/O diagnostics and detection of all normally detectable faults. The minimum toggle rate provides fault coverage of normally undetectable faults within 10% of the calculated mean-time-between-faults (MTBF) for the module. 3. Diagnostic glitching can be disabled by using the OVD disable function. Table 35 3607E Digital Output Specifications Feature Specification Color code Light blue Number of output signals 16, non-commoned Voltage range 44–80 VDC Logic power < 10 watts Current ratings, maximum 1 amp/point, 5 amps surge/10 ms Leakage current to load 2 mA, maximum Fuses (field termination module) 1 per output (1.25 amps fast-acting) Status indicator: On or Off state 1 per point Status indicator: Module status Pass, Fault, Active Status indicator: Field alarm1 Load/Fuse Point isolation 1500 VDC minimum Output diagnostic fault coverage2: Maximum output toggle rate Minimum output toggle rate Every 100 ms Not applicable Diagnostic glitch duration3 2 ms maximum, 500 μs typical On-state voltage drop: At backplane < 2 VDC typical @ 250mA < 3 VDC maximum @ 1A On-state voltage drop: With external termination, 10-foot cable < 3 VDC typical @ 250mA < 4 VDC maximum @ 1A Table 34 3604E Digital Output Specifications (continued) Feature Specification 98 Chapter 2 System Components Planning and Installation Guide for Tricon v9–v10 Systems 24 to 120 VDC Supervised Digital Output Modules This figure is a simplified schematic for models 3623, 3623T, and 3624, which are TMR Supervised Digital Output Modules. Figure 40 3623, 3623T, and 3624 Simplified Schematic On-state voltage drop: With external termination, 99-foot cable < 4 VDC typical @ 250mA < 7 VDC maximum @ 1A Inductive kick-back protection (reverse EMF) Reverse diode on I/O module 1. Power must be supplied to all points, including unused points on non-commoned panels. 2. The maximum output toggle rate enables proper operation of I/O diagnostics and detection of all normally detectable faults. The minimum toggle rate provides fault coverage of normally undetectable faults within 10% of the calculated mean-time-between-faults (MTBF) for the module. 3. Diagnostic glitching can be disabled by using the OVD disable function. Table 35 3607E Digital Output Specifications (continued) Feature Specification Bus Xcvr Point Register Bus Xcvr Point Register Bus Xcvr Point Register Output Switch Drive Circuitry A A and B Output Switch Drive Circuitry Output Switch Drive Circuitry B Output Switch Drive Circuitry C A B C A and B A A B B C C +V A B C TRIPLICATED I/O BUS FIELD CIRCUITRY TYPICAL POINT (16) – Loopback Detector LD RTN INTELLIGENT I/O CONTROLLER(S) * * * * * All output switches are opto-isolated. to other points to other points Loopback De et ctor µProc µProc µProc Digital Output Modules 99 Planning and Installation Guide for Tricon v9–v10 Systems This figure shows the front panels of models 3623, 3623T, and 3624. Figure 41 Components Planning and Installation Guide for Tricon v9–v10 Systems 3623 and 3623T Specifications This table lists the specifications for models 3623 and 3623T, which are TMR Supervised Digital Output Modules with a nominal voltage of 120 VDC. Model 3623 has a point isolation of 1,500 VDC; model 3623T has a point isolation of 2,500 VDC. CAUTION Triconex highly recommends that you perform compatibility testing before selecting the model 3623T module for use in applications that have any of the following: • field wiring lengths over 328 feet (100 meters) • cable that is not twisted pair • atypical loads such as smart devices, strobe lights, or klaxons Table 36 3623 and 3623T Supervised Digital Output Specifications Feature Specification Color code Steel blue Number of output signals 16, commoned Recommended voltage range 90–150 VDC Maximum voltage 160 VDC Logic power < 10 watts Current ratings, maximum 0.8 amps/point, 4 amps surge/10 ms Minimum required load 30 mA Leakage current to load 4 mA, maximum Fuses (field termination) 1 per output (1 amp, fast-acting) Status indicator: On or Off state 1 per point Status indicator: Module status Pass, Fault, Active Status indicator: Field alarm1 Power, Load/Fuse (1 Per Point) Point isolation: 3623 1500 VDC minimum Point isolation: 3623T 2500 VDC minimum Short-circuit detection threshold in Off state < 24 Ω Output diagnostic fault coverage
