表25 3502E数字输入规格特性规格颜色代码深红色输入点32个，共8组输入频率范围DC或47-63 Hz建议输入范围35–95 VAC/VDC最大电压95 VAC/DC开关电平：典型的断开至接通27 VAC/VDC，最坏情况下32 VAC/VDC开关电平：一般的断开到断开14 VAC/VDC，11 VAC/VDC最坏情况典型滞后7 VAC/VDC标称开启6 mA至9 mA输入阻抗>2.9 kΩ标称输入延迟：关至开<8 ms输入延迟：开至关<15 ms点隔离，光隔离最小1000 VAC，最小1500 VDC状态指示器：开或关状态每点1个状态指示器：模块状态通过，故障，活动逻辑功率<10瓦标称现场功率负载1.0瓦/开点，3.2瓦@最大现场电压底盘泄漏电流@60 Hz 0.5 mA/开点输入诊断故障范围1：最大输入切换率1。最大输入切换率可实现I/O诊断的正确操作和所有正常可检测故障的检测。最小切换率提供了模块计算平均故障间隔时间（MTBF）10%内正常不可检测故障的故障覆盖率。每100毫秒输入诊断故障覆盖率1：最小输入切换率，打开状态最小输入切换速率，关闭状态不需要每3个月（由用户手动切换）诊断故障持续时间2 2。VIN是施加到通电点的电压。在诊断故障持续期间，相邻断电点上的输出电压很明显。请注意，故障输出可能会错误地激励另一台设备的并联输入。20 ms典型输出电压<1/2VIN输出阻抗<4.22 kΩ78第2章Tricon v9–v10系统3503E规格系统组件规划和安装指南本表列出了3503E型号的规格，该型号为TMR数字输入模块，标称输入电压为24 VAC/VDC，具有自检功能。警告：本型号不建议与并联二极管本质安全栅一起使用。对于这些应用，Triconex推荐3505E型。表26 3503E数字输入规格特性规格颜色代码深红色输入点32的数量，共8个输入频率范围DC或47-63 Hz建议输入范围20–42.5 VDC最大电压42.5 VAC/VDC切换电平：关到开15 VAC/VDC典型值，18 VAC/VDC最坏情况切换电平：开到关8 VAC/VDC标准值，6 VAC/VDC最坏情况典型滞后4 VAC/VDC标称开启6 mA至9 mA输入阻抗>1.25 kΩ标称输入延迟：关至开<8 ms输入延迟：开至关<15 ms点隔离，光隔离最小1000 VAC，最小1500 VDC状态指示器：开或关状态每点1个状态指示器：模块状态通过，故障，有源逻辑功率<10瓦标称现场功率负载0.5瓦/开点1 1.5瓦@最大现场电压1。当与典型的并联二极管本质安全栅一起使用时，每个接通点的标称场功率约为350毫瓦@24 VDC。底盘泄漏电流@60 Hz，每点最大0.25 mA输入诊断故障范围2：最大输入切换率最小输入切换率，打开状态最小输入切换速率，关闭状态每100 ms不需要每3个月（由用户手动切换）诊断故障持续时间3输出电压输出阻抗20 ms典型值<1/2 VIN<1.87 kΩ数字输入模块79 Tricon v9–v10系统3505E规格规划和安装指南此表列出了3505E型的规格，它是一个低阈值TMR数字输入模块。2.最大输入切换率可实现I/O诊断的正确操作和所有正常可检测故障的检测。最小切换率提供了模块计算平均故障间隔时间（MTBF）10%内正常不可检测故障的故障覆盖率。3.VIN是施加到通电点的电压。在诊断故障持续期间，相邻断电点上的输出电压很明显。请注意，故障输出可能会错误地激励另一台设备的并联输入。
Table 25 3502E Digital Input Specifications Feature Specification Color code Dark red Number of input points 32, commoned in groups of 8 Input frequency range DC or 47-63 Hz Recommended input range 35–95 VAC/VDC Maximum voltage 95 VAC/VDC Switching level: Off to On 27 VAC/VDC typical, 32 VAC/VDC worst-case Switching level: On to Off 14 VAC/VDC typical, 11 VAC/VDC worst-case Typical hysteresis 7 VAC/VDC Nominal turn-on 6 mA to 9 mA Input impedance > 2.9 kΩ nominal Input delay: Off to On < 8 ms Input delay: On to Off < 15 ms Point isolation, opto-isolated 1000 VAC minimum, 1500 VDC minimum Status indicator: On or Off state 1 per point Status indicator: Module status Pass, Fault, Active Logic power < 10 watts Nominal field power load 1.0 watts per On point, 3.2 watts @ maximum field voltage Leakage current to chassis @ 60 Hz 0.5 mA maximum per On point Input diagnostic fault coverage1: Maximum input toggle rate 1. The maximum input toggle rate enables proper operation of I/O diagnostics and detection of all normally detectable faults. The minimum toggle rate provides fault coverage of normally undetectable faults within 10% of the calculated mean-time-between-faults (MTBF) for the module. Every 100 ms Input diagnostic fault coverage1: Minimum input toggle rate, On state Minimum input toggle rate, Off state Not required Every 3 months (manually toggled by the user) Diagnostic glitch duration2 2. VIN is the voltage applied to an energized point. Output voltage is noticeable on an adjacent deenergized point for the duration of the diagnostic glitch. Be advised that the glitch output may falsely energize the paralleled input of another piece of equipment. 20 ms typical Output voltage < 1/2VIN Output impedance < 4.22 kΩ 78 Chapter 2 System Components Planning and Installation Guide for Tricon v9–v10 Systems 3503E Specifications This table lists the specifications for model 3503E, which is a TMR Digital Input Module with a nominal input voltage of 24 VAC/VDC and a self-test feature. CAUTION This model is not recommended for use with shunt-diode intrinsic safety barriers. For these applications, Triconex recommends the model 3505E. Table 26 3503E Digital Input Specifications Feature Specification Color code Dark red Number of input points 32, commoned in groups of 8 Input frequency range DC or 47-63 Hz Recommended input range 20–42.5 VDC Maximum voltage 42.5 VAC/VDC Switching level: Off to On 15 VAC/VDC typical, 18 VAC/VDC worst-case Switching level: On to Off 8 VAC/VDC typical, 6 VAC/VDC worst-case Typical hysteresis 4 VAC/VDC Nominal turn-on 6 mA to 9 mA Input impedance > 1.25 kΩ nominal Input delay: Off to On < 8 ms Input delay: On to Off < 15 ms Point isolation, opto-isolated 1000 VAC minimum, 1500 VDC minimum Status indicator: On or Off State 1 per point Status indicator: Module status Pass, Fault, Active Logic power < 10 watts Nominal field power load 0.5 watts per On point1 1.5 watts @ maximum field voltage 1. When used with a typical shunt-diode intrinsic safety barrier, the nominal field power per On point is approximately 350 milliwatts @ 24 VDC. Leakage current to chassis @ 60 Hz 0.25 mA maximum per On point Input diagnostic fault coverage2: Maximum input toggle rate Minimum input toggle rate, On state Minimum input toggle rate, Off state Every 100 ms Not required Every 3 months (manually toggled by the user) Diagnostic glitch duration3 Output voltage Output impedance 20 ms typical < 1/2 VIN < 1.87 kΩ Digital Input Modules 79 Planning and Installation Guide for Tricon v9–v10 Systems 3505E Specifications This table lists the specifications for model 3505E, which is a low-threshold TMR Digital Input Module. 2. The maximum input toggle rate enables proper operation of I/O diagnostics and detection of all normally detectable faults. The minimum toggle rate provides fault coverage of normally undetectable faults within 10% of the calculated mean-time-between-faults (MTBF) for the module. 3. VIN is the voltage applied to an energized point. Output voltage is noticeable on an adjacent deenergized point for the duration of the diagnostic glitch. Be advised that the glitch output may falsely energize the paralleled input of another piece of equipment.
